surveillance camera 8ch 720p cvi camera kit HDMI 1 Mp 4 indoor dome and 4 outdoor bullet CCTV security cctv system
- 100000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
- 7 inch TFT Monitor DIGITAL Wireless Farm Cctv Systems
- 7 inch TFT Monitor DIGITAL Wireless New Backup Camera Kit with 2.4GHz digital signal
- 7 inch TFT Monitor Digital Reversing Camera System with 2.4GHz digital signal
- 7 inch TFT Monitor Wireless Back Up Systems with 2.4GHz digital signal
- Car Camera Wireless Transmitter System For Bus
- 7inch digital 2.4g wireless surveillance camera system For Bus
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Tollar | Model Number: | TL-N80DB-8H1 |
Type: | Digital Camera | Style: | Other, 4 indoor dome and 4 outdoor bullet video cameras | Sensor: | Other, HD 720P CVI Camera + 720P CVI DVr |
Technology: | Infrared | Special Features: | Other, Waterproof / Weatherproof, H.264 8CH 720P CVI KIT support cloud p2p plug and play |
Product Description
Specifications
Specifications surveillance camera:1.HD camera kit 8ch CVI
2.4pcs Indoor CVI Cameras + 4pcs outdoor CVI Cameras+8CH 720P
P2P dvr system 8ch 720P CVI kit HDMI DVR 1 Mp 4 indoor dome and 4 outdoor bullet CCTV Security Camera System
CVI KIT Specification:
Image Sensor | 1/3" 1 Megapixel CMOS HD CVI 720P |
Resolution | 1280*720 |
Video Frame Rate | 720p 25/30fps |
Synchronization | internal |
Min.illumination | 0.002Lux F1.2(AGC ON),0Lux IR on |
Video Output | 1-channel BNC HD CVI high definition video output/CVBS standarddefinition video output(can switch) |
camera Features | |
Lens | 3.6mm MP MRT |
LED | 24pcs F5 LEDS |
IR Range | 10-25M |
Day/Night | Auto(ICR)/Color/ B/W |
General | |
Power supply | DC12V±10% |
Working Environment | -30℃~+60℃/Less than 95%RH(no condensation) |
Transmission Distance | Over 500M via 75~3 Coaxial Cable |
Ingress Protection | IP67 |
CVI DVR Data:
Model | TL-CVD7004 | TL-CVD7008 |
Main Prcessor | Embedded processor | |
Operating system | Embedded LINUX | |
Video Input | 4 channel,BNC | 8channel,BNC |
Standard | NTSC(525Line,60f/s),PAL(625Line,50f/s) | |
Display Interface | 1 HDMI,1VGA,1BNC | |
Resolution | 1920*1080,1280*1024,1280*720,1024*768,800*600 | |
Display Split | 1/4 | 1/4/8/ |
Privacy Masking | 4 rectangular zones(each camera) | |
OSD | camera title,Time,Video loss,Camera lock,Motion detection,Recording | |
Video/Audio compression | H.264/G.711 | |
Resolution | 720P(1280*720/1280*600)/960h(960*576/960*480)/D1/4CIF(704*576/704*480)/CIF(352*288/352*240)/QCIF(176*144/176*120) | |
Record Rate Main stream Extra Stream | 720P/960H/D1/HD1/2CIF/CIF(1-25/30fps) | |
CIF/QCIF(1-25/30fps) | ||
Bit Rate | 48-6144kb/s | |
Record Mode | Manual,Schedule(Regular(continuous),MD),Stop | |
Record Interval | 1-120min(default;60min),Pre-record;1-30sec,Post-record:10-300 | |
Trigger Events | Recording,PTZ,Tour,Video Push,Email,FTP,Spot,Buzzer&Screen | |
Video Detection | Motion Detection,MD Zones:396(22/8),Video loss&camera Blank | |
Alarm Input | 4 channel | 8 channel |
Sync Playback | 1/4 | 1/4/8/ |
Search Mode | Time/Date,MD&Exact search(accurate to second) | |
Playback Functions | Play,Pause,Stop,Rewind,Fast play,Slow play,Next file,Previous file | |
Backup Mode | USB Device/network | |
Network Ethernet | RJ-45 port(10/100M/1000M) | |
Network Functions | HTTP,IPv4/IPv6,TCP/IP,UPNP,RTSP,UDP,SMTP,NTP,DHCP,DNS | |
Max User Access | 128 users | |
Smart Phone | iphone,ipad,Android,Windows,Phone | |
Power supply | DC12V |
Picture:
1.After-sale service
All our products have 2 years warranty
Welcome to VIST OUR FACTORY AND TEST OUR samples!
2. Faster delivery:
Within 1-3 days for sample payment received
Within 3-7 days for medium & large order after payment received
3.Delivery term:
By Express(DHL/FEDEX/TNT/UPS/EMS).By Air ,By Sea.
