Modern house design cheap commercial architectural glass for curtain wall l

Packing:architectural glass for curtain wall l will be wrapped in plastics film and paper.
All hardware of terrace glazing will be packed in separate boxes and marked correspondingly.

Modern house design cheap commercial architectural glass for curtain wall l

You Need a Service!

There are no frames between glass panels and each glass panel can freely slide to the left or right to open for ventilation or cleaning purpose with Finzone10 terrace glazing. Total or partial balcony enclosure or opening is achieved.The characteristics of Finzone10 terrace glazing makes the cleaning of the windows to be very easy,you can clean the reverse and facade with every glass panel.The balcony installed with Finzone10 terrace glazing looks like a transparent package balcony,which not only doesn't damage the appearance and style of the building,but also contributes a lot to the integral beauty of the balcony.

System features for architectural glass for curtain wall l

Latest system: Finzone10 used for most kinds of balcony shape, special for terrace glazing.

Compensation profile: There is a compensation profile for upper profile that can adjust the gap between the window and ceiling.

Best Rollers: Use big ball bearing wheels and slide smoothly.

Big glass panels: The max width of Finzone10 is 750mm and the max height is 2800mm for each glass panel.

Hinge axles: Use SS304 for the whole hinge axles so that can stand big weight and avoid the glass panels falling down.

Protection cap: Apply nylon protection cap on glass profiles to avoid hurting.

Connection hardware: Use two parts of Zinc that easy to connect two track profiles with any angles.

Structure drawing for architectural glass for curtain wall l

Mechanical properties for architectural glass for curtain wall l

The guide profiles are made in compliance with 6063T5 as special profiles

Tensile strength of the frame from the guide profile: 860 kg

Guide profile deflection 80 kg / 3.8 m:

Perpendicular: 3.5 cm

Horizontal: 7.5 cm

No permanent changes in shape

Each glass element is supported by four 8 mm hinge axles, featuring a total of 10 horizontal wheels

Durability of Nylon bearing wheel in random profile loading: undamaged over 600 kg Gearing heat resistance (POM): approx +90 Degree C

Frost resistance: over -30 Degree C

All metal parts are non-corrodible: only aluminum and stainless steel

Installation on concrete and brick surface is by 8 mm stainless steel bolts and brass anchor

Sound insulation for architectural glass for curtain wall l

For 100 Hz Reduction 6.7 dB

For 2400 Hz Reduction 13.5 dB

Measured according to international standards ISO 140-5 & ISO 717-1

Wind pressure for architectural glass for curtain wall l

Finzone10 terrace glazing can support the wind speed according to the panel height and glass thickness

Function for architectural glass for curtain wall l's shapes

Color choice for architectural glass for curtain wall l:

Customers coming for architectural glass for curtain wall l

 Exhibitions for architectural glass for curtain wall l

Effective Factory for architectural glass for curtain wall l

Certificates for architectural glass for curtain wall l

architectural glass for curtain wall l
