Home > Auto, Motorcycle Parts & Accessories > Car Light & Auto Mirror > Headlight > Super Bright 12V 75W HID Xenon Ballast,Xenon Hid Ballast,hid Ballast for Hid Bulb

Super Bright 12V 75W HID Xenon Ballast,Xenon Hid Ballast,hid Ballast for Hid Bulb

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Headlight

Voltage:

12V

Lamp Type:

HID Xenon

Guangzhou Northern Star E-Technology Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

GuangZhou

Delivery Detail:

Delivery time depends on order quantity.

Type Headlight

Voltage 12V

Lamp Type HID Xenon

Certification CE,E-mark

Car Make All of cars,trucks

Place of Origin Guangdong, China

Brand Name OEM

Model Number 75W ballast

Specifications

Color temperature:4300K,6000K,8000K
warranty is 1year

	12V 75W Ballast
Applicance performance	Standard	Product actual text
Lumen		90Lm per 1Watt
Bulb Open circuit protection test	<1.5 second stop working	√
Power short circuit protection test	<High voltage cable within2 seconds stop working	√
Input power reversed connect protection test	after reversed connect keep normal work,no damage	√
Over Voltage Protection test	Can not exceed MAX32V	MAX32V
Low Voltage Protection(Power off)	≤9V	9V
Cold Start Current	Voltage13.2V,≤9A	13.2V=9A
Hot Start Current	Voltage13.2V,≤9A	5A
Stable Current	Voltage13.2V,≤8A	3.5A
Stable Output Power	Voltage20-30V,Voltage fluctuating:±3W	√
Stable Bulb Power	75W±5W	77W
Inside consumed Power	≤15W	12W
Flash Text	Each 2 seconds On and Off,work under normal situation	√
High Voltage isolated protection	Resistance≥1MΩ	√
Lowest Start Power	≥20.5V	20V
Bulb Working frequency	300Hz	300Hz
Ballast working Temperature	after light 20min,Circumstance ≤ 25°C	30°C
Ballast Efficiency	≥85%	87%
Input touch shake	Automatically reset within 1.2 seconds	Reaction time:0.1 sec
Working Voltage Range	20-32V DC	√
Electric Wave Radiation	Fit National Standard	√
Max Current	≤15A	MAX 0.01sec
Bulb working voltage	95~150V AC Square wave
Start Max Voltage	26KV
When install ballast please add our special relay

Length	151mm
Width	97mm
Height	36mm
