Specifications
8-layer Rogers PCB board high frequency circuit boardISO,UL,CE, lead free
no MOQ
high quality but high price
fast delivery
Welcome to Rigao Electronics .CO.,Ltd.
Why Choose us ?
--We're the PCB & PCBA Manufacturer, Provide OEM PCB, PCBA
--We have years of experience in PCB/PCBA field.
--Mixed-technology (High speed SMT & Through hole assembly)
--PCB Design & Assembly and copy service
--Prototyping
--Components purchasing
--Our products are ISO,UL,CE approved
--Good quality , Sincere Service and compective price.
--Fast turn around
Our factory:
Application
Products are applied to a wide range of High-tech industries such as: LED lighting,
telecommunication, computer application, lighting, game machine, industrial
control, power,automobile and high-end consumer electronics, ect.
By unremitting work and effort to the marketing, products exports to American,
Canada, Europe counties,Africa and other Asia-pacific countries.
Products
Quality Certificates:
Lead free,ISO,UL,CE
Specs
| 1 | Layer | 1-22layer |
| 2 | Material | Rogers ,FR4, CEM1, Aluminium Base, Cooper Base, High frequency material , |
| Thick copper foil,94-V0 (HB), PI Material, Roger,High TG:SL S1000-2,ITEQ:IT180. | ||
| 3 | Board thickness | 0.2mm-7mm |
| 4 | Max.finished board side | 610mm*1200mm |
| 5 | Min.drilled hole size | 0.25mm |
| 6 | Min.line width | 0.1mm(4mil) |
| 7 | Min.line spaceing | 0.1mm(4mil) |
| 8 | Surface finish/treatment | HASL,HASL lead free,OSP,Immersion tin,Immersion Gold, |
| Immersion Silver/Gold Finger ,Gold Plating,Selective OSP Immersion Gold | ||
| 9 | Copper thickness | 1-6 oz |
| 10 | Solder mask color | green/black/white/red/blue/yellow |
| 11 | Inner packing | Vacuum packing,Plastic bag |
| 12 | Outer packing | Standard carton packing |
| 13 | Hole tolerance | PTH:±0.076,NTPH:±0.05 |
| 14 | Profiling Punching | Routing,V-CUT,Beveling |
| 15 | Assembly Service | Providing OEM service to all sorts of printed circuit board |
If you have any question , please feel free to let me know , we'll always be on service of you .
