Specifications
DIN371 Spiral Point Taps1.Guaranteed High speed steel Material.
2.Strict heat treatment
3.Precisely Processing.
DIN371 Spiral Point Taps
Specification:
Machine taps: Thread is made of high speed steel material by grinding after heat treatment. Compare
with hand tap, the precision is more higher. It has quick cutting speed and long lifespan.
| 1. Standard: | DIN371(Metric size/UNC/UNF/BSF) |
| 2. Material: | HSS 4341(W4Mo3Cr4V), HSS 6542(W6Mo5Cr4V2), M35 (W6Mo5Cr4V2Co5) |
| 3. Flute: | Straight flute |
| 3. Hardness: | HSS4341:HRC63-64, HSS 6542:64-65, HSS M35:HRC 66-67 |
|
4. Surface finishing: |
Bright finishing;Tin-coated; or customization |
| 5.Application: |
For drilling internal threads. Used for through hole and blind hole machining with the material of cast iron and common steel.(Hole depth below 1.5d) |
6. Size: M1.6*0.35 To M10*1.5
1/16BSW To 3/8-20BSF
NO.1-64UNC To 3/8-16UNC
NO.1-72UNF To 3/8-24 UNF
