Help CenterDIN352 HSS Hand Tap Set
US$ 1.5 - 10
MOQ: 100 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
TONGYU
Model Number:
TY6
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Carbon Steel, Alloy Steel, HSS Hand TapUS$ 1 - 30MOQ: 100 Pieces -
BSPT Taper Pipe TapsUS$ 0.71 - 40MOQ: 100 Pieces
-
DIN352 3pcs Hand Tap SetUS$ 1 - 5MOQ: 200 Sets
-
DIN371 HSS Machine Taps Form BUS$ 0.9 - 18MOQ: 200 Pieces
-
DIN371 HSS Machine Taps Form C, 35 Degree RSPUS$ 0.9 - 18MOQ: 200 Pieces
Place of Origin
Jiangsu, China
Brand Name
TONGYU
Model Number
TY6
Type
Tap
Number of Pieces
3PCS
Specifications
one set includes:1 taper: 5-6 thread chamfer
2 -plug: 4-5 thread chamfer
3 -final tap: 2-3 thread chamfer
DIN352 HSS Hand Tap Set
one set includes:
1 - taper (taper tap): 5-6 thread chamfer
2 - plug (second tap): 4-5 thread chamfer
3 -final tap: 2-3 thread chamfer
Sizes for Metric:
| M1.0X0.25 | M1.1X0.25 | M1.2X0.25 | M1.4X0.30 | M1.6X0.35 |
| M1.7X0.35 | M1.8X0.35 | M2.0X0.40 | M2.2X0.45 | M2.3X0.40 |
| M2.5X0.45 | M2.6X0.45 | M3.0X0.50 | M3.5X0.60 | M4.0X0.70 |
| M4.5X0.75 | M5.0X0.80 | M6.0X1.00 | M7.0X1.00 | M8.0X1.25 |
| M9.0X1.25 | M10X1.50 | M11X1.50 | M12X1.75 | M14X2.00 |
| M16X2.00 | M18X2.50 | M20X2.50 | M22X2.50 | M24X3.00 |
| M27X3.00 | M30X3.50 | M33X3.50 | M36X4.00 | M39X4.00 |
| M42X4.50 | M45X4.50 | M48X5.00 | M52X5.00 | M56X5.50 |
| M60X5.50 | M64X6.00 | M68X6.00 |
Materil we could supply : HSS-Co5%, HSS-M2, HSS-4341
1. For HSS-Co5% material , it's also named M35, the HRC could be arrived 65HRC-69HRC and keep enough flexibility. This kind of material is good at stainless steel and other special material
2. For M2 mateial , it's also named HSS-6542 in China and the HRC is from 62-65 , and it's the normal widely used in
all over the world.
3. For HSS-4341 materil , it's cheaper than M2 and M35 , and the HRC also could arrive about 64.
