3mm Oval Shape Led

Name: 3mm Oval Shape Led
Brand: ATI, ATI
SKU: 132251857

US$ 0.01 - 0.01 MOQ: 1000 Pieces

Key Specifications

Model Number:

ATI-3ODRN-S

Chip Material:

InGaN

Emitting Color:

Other, R, Y, B, G, A, WHITE

ATI Electronics Technology Limited (Wuxi)

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Model Number ATI-3ODRN-S

Chip Material InGaN

Emitting Color Other, R, Y, B, G, A, WHITE

Luminous Intensity 1000-2000MCD

Luminous Flux(lm) 6-7

Optical Attenuation(%) 3

Power 0.06W

Power Dissipation 0.01

Color Rendering Index(Ra) 80

Color Temperature Customized

Operating Temperature(℃) -30, 80

Storage Temperature(℃) -30, 80

Place of Origin Jiangsu, China

Brand Name ATI, ATI

Certification CE

Product Description

3mm led—Our Products Stand out of Others

Over 12 years producing experience as the vendor of Samsung,Haier,LG etc.

Big scale of producing makes sure that your purchase cost is lower.

Advanced production line guarantees stable quality and long life span.

ELECTRICAL/OPTICAL CHARACTERISTICS AT Ta=25°C:

ITEM	COLOR	view angle	WAVELENGTH	VF	IF	IV
3mm oval LED	RED	40/120°	620~630NM	1.8~2.3V	20mA	1500mcd
3mm oval LED	GREEN	40/120°	520~525NM	3.0~3.4V	20mA	3000mcd
3mm oval LED	BLUE	40/120°	460~465NM	3.0~3.4V	20mA	1500mcd
3mm oval LED	YELLOW	40/120°	590~595NM	1.9~2.4V	20mA	1200mcd
3mm oval LED	ORANGE	40/120°	600~605NM	1.8~2.4V	20mA	1500mcd
3mm oval LED	WARM WHITE	40/120°	2700~3000K	3.0~3.4V	20mA	4~6LM
3mm oval LED	NETURAL WHITE	40/120°	4000~4500K	3.0~3.4V	20mA	5~7LM
3mm oval LED	PURE WHITE	40/120°	6000~6500K	3.0~3.4V	20mA	5-7LM

ITEM	COLOR	View angle	WAVELENGTH	VF	IF	IV
5mm oval LED	RED	40/120°	620~630NM	1.8~2.3V	20mA	1500mcd
5mm oval LED	GREEN	40/120°	520~525NM	3.0~3.4V	20mA	3000mcd
5mm oval LED	BLUE	40/120°	460~465NM	3.0~3.4V	20mA	1500mcd
5mm oval LED	YELLOW	40/120°	590~595NM	1.9~2.4V	20mA	1200mcd
5mm oval LED	ORANGE	40/120°	600~605NM	1.8~2.4V	20mA	1500mcd
5mm oval LED	WARM WHITE	40/120°	2700~3000K	3.0~3.4V	20mA	4~6LM
5mm oval LED	NETURAL WHITE	40/120°	4000~4500K	3.0~3.4V	20mA	5~7LM
5mm oval LED	PURE WHITE	40/120°	6000~6500K	3.0~3.4V	20mA	5-7LM
