3528 Smd Led, White 3528 Smd Led
- Shanghai or Ningbo
- T/T D/P D/A Credit Card PayPal
You May Like
-
Led Diode 5050, Smd 5050 Led Diode, 5050 Tri-color Smd Led
-
1206 Red Color Led Chip, 1206 Led Chips, 1206 SMD Led
-
0805 Red Color Led Chip, 0805 Led Chips, 0805 SMD Led
-
0603 Red Color Led Chip, 0603 Led Chips, 0603 SMD Led
-
Led Diode 5050, 5050 Smd Led, 5050 White Led Chip
-
1206 Green Color Led Chip, 1206 Led Chips, 1206 SMD Led
Product Details
| Model Number | ATI-3528PWHB-SLM-30 | Chip Material | InGaN | |
| Emitting Color | Natural White | Luminous Intensity | 1500-3000mcd | |
| Luminous Flux(lm) | 7~9 | Optical Attenuation(%) | 0.05 | |
| Power | 0.06W | Power Dissipation | 0.02 | |
| Color Rendering Index(Ra) | 80 | Color Temperature | 6000~6500 | |
| Operating Temperature(℃) | -20, 60 | Storage Temperature(℃) | -30, 70 | |
| Brand Name | ATI-smd 3825 led white | Certification | CE |
Product Description
smd 3825 led white Features—Our Products Stand out of Others
Over 12 years producing experience as the vendor of Samsung,Haier,LG etc.
Big scale of producing makes sure that your purchase cost is lower.
Advanced production line guarantees stable quality and long life span.
ELECTRICAL/OPTICAL CHARACTERISTICS AT Ta=25°C:
PARAMETER | SYMBOL | TEST CONDITION | Color | MIN | TYP | MAX | UNIT |
Forward Voltage | VF | IF=20mA | White | 3.0 | 3.2 | 3.6 | V |
Reverse Current | IR | VR=5V | White | 10 | μA | ||
Peak Emission Wavelength | CT | IF=20mA | White | 6000 | ----- | 6500 | K |
Luminous Intensity | IV | IF=20mA | White | 7 | --- | 9 | LM |
Perfect Product Package—We Care about Your Goods and You
smd 3825 led white Production Line—Make Your Choice to be The Best
smd 3825 led white Certifications—No Worry for Our Products
SMD LEDs —More Choices for Your Purchase
More Information, You Could Easily Contact Us
...
Contact Us
- ATI Electronics Technology Limited (Wuxi)
- Address, Wuxi, Jiangsu
