1.6m Double 4 Color UV Flatbed Printer

1.6m  double 4 color UV flatbed  printer

CHAMPION OF STABLE---------

----------- LONG TIME PRINTING-----UV PRINTER

 PRINTER INTRODUCTION



 FEATURE



Piezoelectric Print Head Variable Ink Droplet

With double DX5 print heads of  parallelogram layout, as well as 1440 nozzles for each print head, performs excellently in higher speed and high quality output in 1440dpi.



Min 3.5pl Variable Ink Droplet

With excellent function to print with different ink droplet during



each printing, as well as the minimum 3.5pl ink droplet, will performs smooth and bright output.





SPECIFICATIONS



Model		GD-RF1600UV2
Print Head		Double Heads
Priting Technology		Piezoelectric Inkjet
Media Width		210-1620mm-1.6M
Media Width	Type	Roll or Sheet
	Thickness	Maximum 1.5mm
	Roll Weight	40kg
Ink Cartridge	Type	UV curing Ink(without VOC)
	Capacity	220ml/440ml Refill Cartridge
	Color	CMYK Lc Lm White
Ink Supply		Continuous Ink Supply Cartridge
Color Gamut Performance		1670 Million Color
Media Control		Automatic Feeding System and Sheet Cutter
Media Sensors		Paper Sensor & Width Sensor
Print Head Cleaning		Automatic Cleaning and manual cleaning
Programming Language		RD-RTL,RD-PJL
Interface		USB2.9/HIUSB
Power Requirement	During Operation	100V to 240V±10%,50/ 60 Hz
	Sleep Mode	100V to 240V±10%,50/ 60 Hz
Power-saving Function		Automatic Power Saving
Acousic Noise Leve	During Operation	≤65 dB (according to ISO 7779)
	During Standby	≤40 dB (according to ISO 7779)
Package Dimension (with stand)		3000mm(W)x1800mm(D)x1260mm(H) - 1.6M Printer
Weight(with stand)		400kg ( 1.6M )
Power Consumption		≤1500VA
Environment	Power On	Temperature: 20 to 32°C  Humidity: 35 to 80%RH (non-condensing)
	Power Off	Temperature: 5 to 40°C   Humidity: 20 to 80%RH (non-condensing)
Accessories		Power Cord, Drain Bottle, Manual



 APPLICATION



 FACTORY SHOW

OUR SERVICE

24-Hour Online Service

Pre-Sales Service                                                            After-Sales Service

*Inquiry and consulting support                                                    * Training how to install the machine and training use

*Sample testing support                                                                * Engineers availa to service machine overseas

* View our factory                                                                             * One year warranty
