1.8m Inkjet Direct Sublimation Printer With Four DX5 Printhead

1.8m Inkjet Direct Sublimation Printer With Four DX5 Printhead thumbnail-1
1.8m Inkjet Direct Sublimation Printer With Four DX5 Printhead photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai SD Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Shanghai, China
Brand Name Grando
Model Number HT180-E4
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade Automatic
Voltage 110V/220V
Dimensions(L*W*H) 3420*2200*1780
Weight 2000kgs
Certification CE Certification
After-sales Service Provided Engineers available to service machinery overseas

DIRECT SUBLIMATION PRINTER---------



----------- GD-HT180-E4







1.8m Inkjet direct sublimation Printer with Four DX5 Printhead

 PRINTER INTRODUCTION





Conduction band-type digital printing machine is the most innovative direct-injection device.It builds on the characteristics of the traditional printing machne.it uses the printig belt conveying way,which adds automatic conduction band washing device,drying system and includes most functions of traditional printing machine.It uses advanced servo transmission system to ensure the accuracy of printing on bits and can achieve the production of digital printing on fabrics such as cotto and linon,terylenne,chinlon and synthetic fiber.




 FEATURE



Widespread applications

Using the latest color control and managemant system.Acid ink can be usd to print on silk and chinlon,while active ink can be used for cotton.At the same time,paint and dispersive fuel can be used to print on terylene and synthetc fiber.







High_speed production-level printhead

With 360 nozzles per color jetting at the same time,and each printing machine is equipped with a 1-inch high-precision nozzle.





High-speed data processing and transmission

Ethernet 100 BASE-TX and bi-directional parallel interface transmission,the two data transmission modes are simple and  efficient.





Adopt professional RIP

RIP and printing output processing simutaniously can be achieved,which greatly improved the production efficiency.It is compatible with postscript language,photoshop,coreldraw,llusrator and Freehand,Supporting TIF,JPEG,EPS,PS,PDF,DCS2.0 and other file formats.



Professional channel control technology

Can bring each channel under control,and ensure color consistency of digital printing and flat screen,round screen printing.

Adopt advanced conduction band transmission device and automatic correction compilation unit.Installtion of printhead lifting device can adapt to a variety pf fabrics.




1.8m Inkjet direct sublimation Printer with Four DX5 Printhead


SPECIFICATIONS

Model GD-HT180-E4
Printing Method Piezoelectric Print Head
Print Head Four Head
Max Printing Width 180cm
Printing Resolution 540dpi,720dpi,1440dpi
Printing Mode 2psss,3pass,4pass,6pass,8pass,12pass
Printing Speed 70m²/h
Ink Capacity 1000cc per color
Heating System Three Phase Yes
Dry System Standard intelligient infrared ay heating/fan system
Automatic Media Feeding/Rolling System Standard Configuration
Environment Temperature 15-27℃   Relative Humidity 40%-65%
Dimension(W*D*H)Weight 3420*220*1780/2000kgs



 APPLICATION



1.8m Inkjet direct sublimation Printer with Four DX5 Printhead







 FACTORY SHOW







 1.8m Inkjet direct sublimation Printer with Four DX5 Printhead







OUR SERVICE







24-Hour Online Service







1.8m Inkjet direct sublimation Printer with Four DX5 Printhead







Pre-Sales Service                                                            After-Sales Service



*Inquiry and consulting support                                                     * Training how to install the machine and training use



*Sample testing support                                                                 * Engineers availa to service machine overseas



* View our factory                                                                              * One year warranty







PACKING & DELIVERY







  1.8m Inkjet direct sublimation Printer with Four DX5 Printhead

Packing

Size

3420*2200*1780

Weight

2000kgs

Details

 on wooden
