HIGH PERFORMANCEPERFECT COMBINATION ---------
----------- OS6045
PRINTER INTRODUCTION
--- High-end design
--- Prefect speed experience
--- Self-developed control system
--- Variety of print configuration
FEATURE
High Speed,High Quality
Piezoelectric Print Head Variable Ink Droplet
With double DX5 print heads of parallelogram layout, as well as 1440 nozzles for each print head, performs excellently in higher speed and high quality output in 1440dpi.
Min 3.5pl Variable Ink Droplet
High Performance
Humanized Printer Protection Design
Printer is equipped with emergency switch and alarm lamp to guarantee customers to grasp the printing status,meanwhile printer gets the ablility to stop printing jobs in hte emergency situation,operates the protection circuit to keep its performance and consistency.
Humanized Printer Protection Design
All-steel manufacturing,every detail reflects our sincerity.Cooperate with international brand like THK,IGUS,which lay a foundation for stability and durability
Model |
OS6045 |
|
Print Head |
dx5 |
|
Maintenance |
AutoClean,AutoMoisture |
|
Resolution |
720dpi;1440dpi |
|
Max Printing Speed |
10m²/h |
|
Ink |
Type |
UV curing Ink |
Color |
CMYK+LC+LM+LK+W+V+Solid C+Primer |
|
Capacity |
200mk |
|
Media |
Max Width |
600mm*450mm |
Max Thickness |
150mm |
|
Max weight |
20KG |
|
Type |
Plastic ,Acrylic,Plank,Metal ,Glass etc |
|
Printing Mode |
Bi-direction/Uni-direction |
|
Port |
USB 2.0 |
|
Configuration |
RAM |
4 GB |
Installation Space |
300M |
|
Power Supply |
AC 220-240V 50HZ |
|
Environment |
Temperature |
19℃-29℃ (60F-85F) |
Humidity |
20-80%Rh |
|
Dimensions(LxWxH) |
1260mmx750mmx800mm |
|
Weight |
100kg |
|
Warranty |
1year |
|
APPLICATION
FACTORY SHOW
OUR SERVICE
24-Hour Online Service
Pre-Sales Service After-Sales Service
*Inquiry and consulting support * Training how to install the machine and training use
*Sample testing support * Engineers availa to service machine overseas
* View our factory * One year warranty
PACKING & DELIVERY
|
|
Packing |
|
Size |
3205mm(L)*1100mm(W)*1430mm(H) |
|
Weight |
700kg |
|
Details |
on wooden |
|
