1.8m Large Format UV Roll to Roll and Flatbed Printer With Double DX5

1.8m Large Format UV Roll to Roll and Flatbed Printer With Double DX5 thumbnail-1
1.8m Large Format UV Roll to Roll and Flatbed Printer With Double DX5 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Letterpress
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai SD Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Letterpress
Place of Origin Shanghai, China
Brand Name Grando
Model Number GD-RF1600-UV2
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade Automatic
Voltage 110V/220V
Dimensions(L*W*H) 3000*1800*1260
Weight 400KG
Certification CE Certification
After-sales Service Provided Engineers available to service machinery overseas

UV PRINTER---------



----------- GD-RF1600-UV2







1.8m large format UV roll to roll and flatbed Printer with Double DX5











 PRINTER INTRODUCTION







---  Focus on both of speed and quality



---  Max 1.6m printing width



---  Full support of top R&D group



---  2 DX5 print head







1.8m large format UV roll to roll and flatbed Printer with Double DX5









 FEATURE



Piezoelectric Print Head Variable Ink Droplet


With Double DX5 print heads of  parallelogram layout, as well as 1440 nozzles for each print head, performs excellently in higher speed and high quality output in 1440dpi.


1.8m large format UV roll to roll and flatbed Printer with Double DX5



Min 3.5pl Variable Ink Droplet

With excellent function to print with different ink droplet during



each printing, as well as the minimum 3.5pl ink droplet, will performs smooth and bright output.

1.8m large format UV roll to roll and flatbed Printer with Double DX5

Perfect Experience of Media Feeding & Rolling system

Adopts media fixing device to ensure smooth media feeding and rolling, at the meanwhile, the rolling bar is djustable anytime, and the media tension bar enables media to enter rolling bar smoothly and completely by enhancing the tension of media.





1.8m large format UV roll to roll and flatbed Printer with Double DX5



User Friendly Mechanical Design

Firm structure enables high speed printing without shake. Adjustable printer stand and feet ensures printer level. Meanwhile, emergency stop button and anticollision device assist customer to make sure printer’s stablity and performance in emergency situations.



1.8m large format UV roll to roll and flatbed Printer with Double DX5



Stable Bulk System Ensures Amazing Printing Speed


Ink cartridges of clamping slot type is easy to install and replace, bulk system ensures continuous smooth ink flow and stable printing. Besides, PWC device assists the bulk system to protects the nozzles from being blocked.



1.8m large format UV roll to roll and flatbed Printer with Double DX5



High Stablity, High Durablity


All-steel struction, igorous and precise manufacturing process even for a small screw, together with international brands such as THK, ensure the stablity and durablity.

1.8m large format UV roll to roll and flatbed Printer with Double DX5


SPECIFICATIONS

Model GD-RF1800-UV2
Printing Method Piezoelectric Print Head
Print Head Double DX5 Head
Ink UV Ink
Max Printing Width 1550cm
Printing Resolution 540dpi,720dpi,1440dpi
Printing Mode 2psss,3pass,4pass,6pass,8pass,12pass
Printing Speed 14m²/h
Ink Capacity 1000cc per color
Heating System Three Phase Yes
Dry System Standard intelligient infrared ay heating/fan system
Automatic Media Feeding/Rolling System Standard Configuration
Environment Temperature 15-32℃   Relative Humidity 35%-80%
Dimension(W*D*H)Weight 3000*1800*1260/400kg



 APPLICATION



1.8m large format UV roll to roll and flatbed Printer with Double DX5







 FACTORY SHOW







 1.8m large format UV roll to roll and flatbed Printer with Double DX5







OUR SERVICE







24-Hour Online Service







1.8m large format UV roll to roll and flatbed Printer with Double DX5







Pre-Sales Service                                                            After-Sales Service



*Inquiry and consulting support                                                     * Training how to install the machine and training use



*Sample testing support                                                                 * Engineers availa to service machine overseas



* View our factory                                                                              * One year warranty







PACKING & DELIVERY







  1.8m large format UV roll to roll and flatbed Printer with Double DX5

Packing

Size

3000*1800*1260

Weight

 400kg

Details

 on wooden
