Help CenterPrecise Grinding Machine
Related Products
Specifications
1.Table Size:410*160mm;Travel:430*200mm2.Processing accuracy<=0.005mm
3.CE Certification
4.Taiwan grinding head
Detailed Product Description
1.Table Size:460*150mm;Travel:480*170mm
2.Processing accuracy<=0.005mm
3.CE Certification
4.Taiwan grinding head
Features
- Twice scraped slide way,which could assure the accuracy of the machine
- High quality electric components
- Radius tolerance of spindle<=0.002mm
- Vertical vertical value of ram slide way <=0.005mm
- Processing accuracy<=0.005
- Long life span, High accuracy
Specification
-
Model 200M Table size 410*160mm Travel (Longitudinal) 430mm Travel (Crossward) 200mm Max.Distance from spindle to table 445mm Spindle (Rotation Speed) 2850rpm Spindle (Rated power) 1.5HP Auto feed of vertical handwheel (1 REV.) 2 Auto feed of vertical handwheel (1 DIV.) 0.01 Grinding wheel size φ200*(6-20)*φ31.75mm Magnet chuck size 150*350mm Dimension 1610*1120*1645mm Net weight 890kg Standard accessories:
Coolant system or dust clean
Working light
Tool and toolbox
Operation manual
4.Optional accessories:
DRO
Magnet chuck
Balancing stand/bracket
After-sales Service:
Warranty is a year. Parts are free of charge to be offered during this period. Oversea service need to charged extra in and out of warranty.
Our development team
We have a group of development team that they have professional theory profound skills, technical specialization, rich experience in the industry of the first-class technical research
Our production workshop
Our company independent planning and construction of modern vertical machine center production line ,CNC milling machine production line ,Dragon frame CNC machine production line , electric discharge machine production line, milling machine production line, grinder machine production line, precise head assembly workshop etc.
ur development team
We have a group of development team that they have professional theory profound skills, technical specialization, rich experience in the industry of the first-class technical research
Our certificate of honor
- There are 8 Intellectual property rights,5 the patent
- In 2008, Our own brand”JOINT” has been the top quality machine’s signal in domestic sales JOINT also has been recognized as”Guangdong Famous Brand”
- In 2008, Milling machine was recognized as” TOP 10 Famous Brand of Milling Machine “ in China
- ,In 2011,our company has been recognized as” national grade HI-Tech Enterprise”.
- The company set up a ISO9001:2000 quality guarantee system
- our product through “the country machine quality supervision and inspection center “certification testing
