HD MI & VGA & Ypbpr & AV Input Dual Stream of H.264/H.265 Iptv Encoder

HD MI & VGA & Ypbpr & AV Input Dual Stream of H.264/H.265 Iptv Encoder thumbnail-1
HD MI & VGA & Ypbpr & AV Input Dual Stream of H.264/H.265 Iptv Encoder photo-1
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
Colable
Model Number:
COL-7201HV
Contact Supplier Request Quote Chat Now
Colable Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name Colable
Model Number COL-7201HV

COL-7201HV Mini H.264/H.265 IPTV encoder for streaming server



Skype ID: yangting965



We are providing complete solution for DVB-C/S/S2/T/T2 system, IPTV system.

Please add my Skype ID or send an inquiry, let's talk more details.







Outline

COL-7201HA Mini H.265/H.264 IPTV encoder is most competitive cost and easy-to-use video streaming appliance designed for professional video producers. The product support 1 channel HDMI & VGA & Ypbpr & AV generating dual stream of h.264/H.265 encoding output and the AAC,Mp3 audio format. From any HDMI &AV input source such as a camera or switcher or DVD, it generates an H.264/H.265-encoded stream compliant with RTSP, HTTP, UDP and RTMP protocols. The product can be applied to education, health care, IPTV, conference, remote education, news interview, banking, transportation and other industries.





Features

ü 1 channel HDMI & VGA & Ypbpr & AV input,

ü Up to 720P, 1080P HD video input

ü Support non-video encoding

ü Support OSD rolling and logo inserting

ü System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN764, LINUX

ü Support MP3 and AAC audio format selection

ü Encoding specification: BASELINE PROFILE / MAIN PROFILE/ HIGH PROFILE

ü Support a click to restore the default configuration

ü Support STB decoding

ü Support Main TS stream and the sub TS stream can use different network protocols for transmission (Multi-rate multi-protocol support)

ü Support multiple devices display at the same time on a computer

ü Support network directly connected, don’t need match HD collection card.

ü Providing RTSP/RTP/HTTP/RTMP/UDP protocol

ü Support H.264 Main Profile/H.264 High Profile and AAC audio.

ü Web control interface

ü Comply with CBR/VBR 16KBIT/S~12MBIT/S standard

ü Power less than 24W, low power watts designing.

ü Support Network interface full-duplex mode 1000M





Technical Specification









Video

Input

1 channel HDMI & VGA & Ypbpr & AV input, support HDCP

Resolution

1920x1080/1280x720/1280x1024/1280x960/704x576

Encoding

H.264/H.265 AVC High Profile Level 4.0(HMDI)

Video Bitrate

0.8Mbps~12Mbps

Bitrate mode

CBR/VBR

GOP type

Adjustable

Video

preprocessing

De-interlacing, noise reduction, sharpening



Audio



Encoding

AAC,MP3

Resample Rate

Adaptive output sample rate (option)

32K, 44.1K, 48K, 64K, 96K, 128K, 160K, 192K

Sampling

24 bit

Bitrate

64Kb/s~384Kb/s



System

RJ45

1000M Ethernet port

Protocol

HTTP,UDP,RTSP,RTMP,ONVIF

Configuration

interface

WEB interface

Upgrade

Software upgrades can be carried out through a network





Environment

Dimensions

(W×D×H): 146mm x 100mm x 45mm

Net Weight

0.5KG

Temperature

0~45℃(work), -20~80℃(Storage)

Power

Requirements

12V / DC

Power

consumption

5W



Application



IPTV digital headend

Accessed NVR for DVR

Internet conferencing system video capture

remote education video system

Hotel TV System

Hospital, Bank, transport agency system





About us Colable Electronics Co., Ltd



specialize in Digital TV broadcasting equipment for more than 10 years, and experienced in Digital Cable/Satellite/ Terrestrial tv broadcasting solution and system, If you have any questions and ideas, please no hesitate to contact us!



  • Our experience: Plenty of practical experiences in building IPTV and DVB systems in many different countries

  • Our product: Satellite receiver/ Demodulator Decoder IRD, Encoder, Multiplexer, Scrambler,  Modulator, Transmitter, Antenna, Set top box, IP Gateway, Transcoder, TS Analyzer, TS Distributor etc.

  • Our service: Life-long technical support

  • Warranty: 1 year,  basically our headend equipments can work as long as 10 years

  • Lead time: 2-5 working days
