GLC-FE-100BX-u, 100Base-BX10-u SFP, 1490TX/1550RX--80km, DDM, BiDi SFP Module/Transceiver
Features
¨ Up to 155Mbps data-rate
¨ 1490nmDFB laser and PIN photodetector for 80km transmission
¨ Compliant with SFP MSA and SFF-8472 with simplex LC or SC receptable
¨ Digital Diagnostic Monitoring: Internal Calibrationor External Calibration
¨ Compatible with RoHS
¨ +3.3V single power supply
¨ Operating case temperature range of 0°C to +70°C (Commercial) or -40°C to +85°C (Industrial)
Applications
¨ SDH STM-1, S-1.1,L-1.1, L-1.2
¨ SONET OC-3 IR1,LR1,LR2
¨ Other optical links
Detail Description
The SFP-BIDI transceivers are high performance, cost effective modules supporting data-rate of 155Mbps and 80km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
| Part Number | Product Description |
| DW-S0345-80CD | BIDI SFP 155M 1490TX/1550RX 80km LC 0ºC ~ +70ºC DDM/DOM |
| DW-S0354-80CD | BIDI SFP 155M 1550TX/1490RX 80km LC 0ºC ~ +70ºC DDM/DOM |
| DW-S0345-80TD | BIDI SFP 155M 1490TX/1550RX 80km LC -40ºC ~ +85ºC DDM/DOM |
| DW-S0354-80TD | BIDI SFP 155M 1550TX/1490RX 80km LC -40ºC ~ +85ºC DDM/DOM |
