Home > Products > SFP Transceiver > DW-D2485-03C 2.5G,dual fiber,850nm,300KM,LC SFP Module
DW-D2485-03C 2.5G,dual fiber,850nm,300KM,LC SFP Module
- 50000 Piece / Pieces per Month
- SHENZHEN
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Guangdong, China | Brand Name: | DONGWE | Model Number: | DW-D2485-03C |
Product Description
Features
uDual dat-rate of 2.5Gbps/1.063Gbps operation
850nm FP laser and PIN phot detcor for 300m transmision.
uCompliant with SFP MSA and SF-8472 with duplex LC recptacle
uDigtal Diagnostic Monitorng:
Internal Calibrationr External Calibration
uCompatible with SONET OC-24-LR-1
uCompatible with RoHS +3.V single power suply
uOperating case tmperature:
Standard : 0 to +70°C
Extende : -20 to +85°C
Industrial : -40 to +85°C
Applications
u 2X Fiber Chanel
u Switch to Switch interface
u Switched backplane applications
u Router/Serve interface
u Other optical transmison system
Other description
uThe SFP transceivers are high performance, cost effective modules supporting
dual data-rate of 2.5Gbps/1.0625Gbps and 550m transmission distance with SMF.
uThe transceiver consists of three sections: a FP laser transmitter, a PIN photogenic integrated with transimpedance preamplifier (TIA) and MCU control unit. Al modules
satisfy class I laser safety Requirements.
uThe transceiver are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Part Number | Description |
DW-D2431-80C | 2.125G,dual fiber,1310nm,80km,LC,0ºC ~ +70ºC |
DW-D2431-40C | 2.125G,dual fiber,1310nm,40km,LC,0ºC ~ +70ºC |
DW-D2485-03C | 2.125G,dual fiber,850nm,300m,LC,0ºC ~ +70ºC |
DW-D1255-16C | 1.25G,dual fiber,1550nm,160km,LC,0ºC ~ +70ºC |
DW-D1255-80C | 1.25G,dual fiber,1550nm,80km,LC,0ºC ~ +70ºC |
DW-D1255-40C | 1.25G,dual fiber,1550nm,40km,LC,0ºC ~ +70ºC |
DW-D1231-40C | 1.25G,dual fiber,1310nm,40km,LC,0ºC ~ +70ºC |
DW-D1231-20C | 1.25G,dual fiber,1310nm,20km,LC,0ºC ~ +70ºC |
DW-D1285-05C | 1.25G,dual fiber,850nm,550m,LC,0ºC ~ +70ºC |
DW-D0355-15C | 155M,dual fiber,1550nm,150km,LC,0ºC ~ +70ºC |
DW-D0355-12C | 155M,dual fiber,1550nm,120km,LC,0ºC ~ +70ºC |
DW-D0355-80C | 155M,dual fiber,1550nm,80km,LC,0ºC ~ +70ºC |
DW-D0331-40C | 155M,dual fiber,1310nm,40km,LC,0ºC ~ +70ºC |
DW-D0331-20C | 155M,dual fiber,1310nm,20km,LC,0ºC ~ +70ºC |
DW-D0385-02C | 155M,dual fiber,850nm,2km,LC,0ºC ~ +70ºC |
1.Competitive price
2. 3 years warranty
3. Reply your inquiry within 2 hours
4. Have large quantity modules in stock, delivery fast
5. Label can be customized, also ODM and OEM service offered
6. 100% new material and good quality
7. Can be compatible with a lot of brands like Cisco, HP, H3C, Extreme, Juniper etc.
8. Capacity: 10,000pcs/day
