GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver thumbnail-1
GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver photo-1
US$ 18 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DONGWE
Model Number:
DW-S1234-20CGUB
Contact Supplier Request Quote Chat Now
Shenzhen Dongwe Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DONGWE
Model Number DW-S1234-20CGUB

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

Product Description

 Features

  • Single Fiber Transceiver with single mode SC receptacle
  • 1310nm burst-mode 1.25G transmitter with DFB Laser
  • 1490nm continuous-mode 2.5G receiver with APD-TIA
  • Meets ITU-T G.984.2 Class B+
  • Digital diagnostic interface compliant with SFF-8472 Rev 9.4, Digital Diagnostic Monitoring (DDM) with external calibration
  • 3.3V Single power supply
  • LVPECL interface logic level for data input
  • CML interface logic level for data output
  • Differential line input/output impedance 100 ohm
  • LVTTL for burst signal input and signal detect output
  • Complies with RoHS directive (2002/95/EC)
  • Operating case temperature: Standard : 0 to +70°C

Applications

  • Gigabit Passive Optical Networks (G-PON) - ONU side



Detail Description

The DW-S1234-20CGUB transceiver is a high performance module for single fiber communications using a 1310nm burst-mode transmitter and a 1490nm continuous-mode receiver. It is used in the optical network terminal (ONT) for GPON ONT Class B+ applications.
The Transmitter is designed for single mode fiber and operates at a nominal wavelength of 1310nm. The transmitter module uses a DFB laser diode with full IEC825 and CDRH class 1 eye safety. It contains APC functions, a temperature compensation circuit  to ensure compliance with G.984.2 requirement at operating temperature, LVPECL data inputs and DC coupling circuit.

The receiver section uses a hermetic packaged APD TIA (APD with trans-impedance amplifier) and a limiting amplifier. The APD converts optical power into electrical current and the current is transformed to voltage by the trans-impedance amplifier. The differential DATA and /DATA CML data signals are produced by the limiting amplifier. The APD TIA is AC coupled to the limiting amplifier through a low pass filter. As the optical input power decreases, the Signal Detect will switch from high to low (de-assert point). As the optical input power is increases, Signal Detect will switch back from low to high (assert point). The assert level is at least 0.5 dB higher than the de-assert level (Signal Detect Hysteresis).



Order Information
Part Number Product Description
GPON OLT SFP
DW-S2443-20CGTB GPON OLT SFP, 2.5G/1.25G, 1490/1310, Class B+, 0ºC ~ +70ºC, DDMI
DW-S2443-20CGTC GPON OLT SFP, 2.5G/1.25G, 1490/1310, Class C+, 0ºC ~ +70ºC, DDMI
GPON ONU SFP
DW-S1234-20CGUB GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, 0ºC ~ +70ºC, DDMI
DW-S1234-20CGUC GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class C+, 0ºC ~ +70ºC, DDMI



Compatible Brands

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver



GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

           GBIC



GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

SFP

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

                      SFP+

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

                  XFP

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

                    X2

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

                 Xenpak

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

                QSFP

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

  SFP GPON ONU/OLT

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

          10G Converter



GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

               CSFP

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

   Direct Attach Cable


Package and shipment

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

Shipment:

International  Express: DHL, FedEx, UPS, TNT and EMS optional

Factory Show

GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver

Our Service

      1.  Competitive price

      2.  3 years warranty
        3.  Reply your inquiry within 2 hours
      4.  Have large quantity modules in stock, delivery fast
      5.  Label can be customized, also ODM and OEM service offered
      6.  100% new material and good quality
      7.  Can be compatible with a lot of brands like Cisco, HP, H3C, Extreme, Juniper etc.
      8.  Capacity: 10,000pcs/day
      9.  Certificates below:

      GPON ONU SFP, 1.25G/2.5G, 1310/1490, Class B+, DDMI, B+ Optical Transceiver
Related Products

You may also be interested in other products like:

WS-G5483                     WS-G5484                WS-G5486               WS-G5487

GLC-T                            GLC-SX-MM                    GLC-LH-SM                   GLC-EX-SM

GLC-ZX-SM                   GLC-BX-D                        GLC-BX-U

SFP-10G-SR                  SFP-10G-LR              SFP-10G-ER            SFP-10G-ZR
