QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver thumbnail-1
QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver photo-1
US$ 300 - 340 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DONGWE
Model Number:
DW-D5685-01CQ
Contact Supplier Request Quote Chat Now
Shenzhen Dongwe Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DONGWE
Model Number DW-D5685-01CQ

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

Product Description

 Features

  • Four-channel full-duplex transceiver modules
  • Transmission data rate up to 14.025Gbit/s per channel
  • 4 channels 850nm VCSEL array
  • 4 channels PIN photo detector array
  • Low power consumption <1.5W
  • Housing isolated from connector ground
  • Operating case temperature 0°C to +70°C
  • 3.3V power supply voltage
  • RoHS 6 compliant
  • Hot Pluggable QSFP form factor
  • Maximum link length of 100m on OM3 Multimode Fiber (MMF)and 150m on OM4 MMF
  • Single MPO connector receptacle
  • Built-in digital diagnostic function

Applications

  • InfiniBand FDR
  • 16x Fibre Channel
  • PCI-e3.0
  • Proprietary High Speed Interconnections
  • SAS 3.0



Detail Description

The DONGWE Technologies DW-D5685-01CQ is a Four-Channel, Pluggable, Parallel, Fiber-Optic
QSFP+ Transceiver for InfiniBand FDR/QDR/DDR/SDR,16G/10G/8G/4G/2G fiber channel , PCIe and SAS
Applications. This transceiver is a high performance module for short-range multi-lane data communication
and interconnect applications. It integrates four data lanes in each direction with 56 Gbps bandwidth. Each
lane can operate at 14.025 Gbps up to 100 m using OM3 fiber or 150 m using OM4 fiber. These modules are
designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical
interface uses a 38 contact edge type connector. The optical interface uses an 12 fiber MTP (MPO)
connector. This module incorporates DONGWE Technologies proven circuit and VCSEL technology to
provide reliable long life, high performance, and consistent service.QSFP+ SR4 is one kind of parallel
transceiver. VCSEL and PIN array package is key technique, through I2C system can contact with module

Order Information
Part Number Product Description
40G QSFP
DW-D4085-01CQ QSFP+ SR4, 40G, 100m on OM3 Fiber MMFand 150m on OM4 MMF
DW-D4085-03CQ QSFP+ SR4, 40G, 300m on OM3 Fiber MMFand 400m on OM4 MMF
DW-D404C-10CQ QSFP+ LR4, 40G, 10km on a standard SM fiber
56G QSFP
DW-D5685-01CQ QSFP+ SR4, 56G, 100m on OM3 Fiber MMFand 150m on OM4 MMF
Compatible Brands

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

Product Serial

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

           GBIC



QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

SFP

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

                      SFP+

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

                  XFP

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

                    X2

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

                 Xenpak

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

                QSFP

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

  SFP GPON ONU/OLT

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

          10G Converter



QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

               CSFP

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

   Direct Attach Cable


Package and shipment

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

Shipment:

International  Express: DHL, FedEx, UPS, TNT and EMS optional

Factory Show

QSFP+ SR4 56G 100m on OM3 Fiber MMFand 150m on OM4 MMF Optic Module Transceiver

Our Service

      1.  Competitive price

      2.  3 years warranty
        3.  Reply your inquiry within 2 hours
      4.  Have large quantity modules in stock, delivery fast
      5.  Label can be customized, also ODM and OEM service offered
      6.  100% new material and good quality
      7.  Can be compatible with a lot of brands like Cisco, HP, H3C, Extreme, Juniper etc.
      8.  Capacity: 10,000pcs/day
      9.  Certificates below:
