SC/UPC Optical fiber Connector
Key Features of SC/UPC Optical fiber Connector
- Low insertion loss
- High return loss
- High interface performance
- Latched push-pull integrated.
- Differential colour coded
- UL standard accessories, comply with RoHS.
Applications of SC/UPC Optical fiber Connector
- Telecom network
- Ethernet network
- Optical laser
- Optical communication equipment
- CATV network
Specification of SC/UPC Optical fiber Connector
| Item | Single mode | Multi mode |
| Insertion loss | PC<0.3dB APC<0.2dB | PC<0.3dB |
| Return loss | PC>45dB APC>60dB | PC>25dB |
| Insert-pull test | 1000 times <0.3dB | |
| Operating temperature | -40℃ ~ +75℃ | |
| Ceramic ferrule spec | 125.5um concentricity deviations:<1um | 127um concentricity deviations:<3um |
| Suitable fiber | PC/APC(9/125um) | PC(50/125um,62.5/125um) |
- Supply multi coded colour
- Supply SM,MM,Simplex & Duplex connectors.
- Supply all set connectors. And accessories(SKD)
- Supply 3.0mm ,2.0mm ,0.9mm boot.
|
|
|
|
|
|
|
|
|
|
|
|
Package
In Carton Box
Shipment:
International Express: DHL, FedEx, UPS, TNT and EMS optional
1. Competitive price
