Fiber Passive Components SM MM 2.0 0.9 MU Connector with Ferrule Optic Connector
Key Features
- Low insertion loss ,high return loss
- Apply for NTT & JIS standard
- Resistance of tensile design
- One-piece slim design
- Comply for RoHS
Applications
- Optical communication equipment
- Telecom network
- CATV network
- Test equipment
- Ethernet network
Specification
| Item | Single mode | Multi mode |
| Insertion loss | PC<0.3dB APC<0.2dB | PC<0.3dB |
| Return loss | PC>45dB APC>60dB | PC>25dB |
| Insert-pull test | 1000 times <0.3dB | |
| Operating temperature | -40℃ ~ +75℃ | |
| Ceramic ferrule spec | 125.5um concentricity deviations:<1um | 127um concentricity deviations:<3um |
| Suitable fiber | PC/APC(9/125um) | PC(50/125um,62.5/125um) |
- Supply SM,MM, Simplex and Duplex connectors
- Supply all set connectors and accessories(SKD)
- Supply ,2.0mm ,0.9mm boot.
|
|
|
|
|
|
|
|
|
|
|
|
Package
In Carton Box
Shipment:
International Express: DHL, FedEx, UPS, TNT and EMS optional
1. Competitive price
