Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Optical Fiber Media Converter

Optical Fiber Media Converter

Name: Optical Fiber Media Converter
Brand: DONGWE
SKU: 132177643

Optical Fiber Media Converter thumbnail-1

US$ 10 - 12.5 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

DONGWE

Model Number:

DW-MCS135-20

Contact Supplier Request Quote Chat Now

Shenzhen Dongwe Electronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Ningbo Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name DONGWE

Model Number DW-MCS135-20

Optical Fiber Media Converter

Product Description

Features of Optical Fiber Media Converter

LFPT (Link Fault Pass Through) Function optional
Provide one Single Fiber Connector and one UTP Connector
Fully Complies with IEEE802.3 10Base-T,IEEE802.3u 100Base-TX/FX standard
Auto-detection of half/full duplex transfer mode for Tx port
Auto-negotiation of 10/100Mbps rate and Auto-MDI/MDIX for Tx port
Provide switch configuration of half/full duplex transfer mode for Fx port
Extend fiber distance up to 120km for single-mode fiber
Indication light:FEF,SPD,100,Link/Act,PWR,FDX
Easy-to-view LED indicators provides status to easily monitor network activity
External power supply and Internal Power Supply

Product Description of Optical Fiber Media Converter

DW-MCS135-20 Media Converter is 10/100Mbps Fast Ethernet Converter. The Converter mediates between
a 10/100Base-Tx segment and a 100Base-FX segment. It is primarily designed for large, higher
speed/bandwidth demanding workgroups that require expansion of the Ethernet network. It can extend the
conventional 10M Ethernet or 100M Fast Ethernet to 20km-120km via the fast Ethernet Fiber-optical Line. It is
high-performance, cost effective and flexible solutions for a wide range of applications in the field of LAN campus network

Specification of Optical Fiber Media Converter

* For further reports, please kindly contac us for update.

Ordering Information

Part Number	Description
DW-MCS135-20 DW-MCS153-20	10/100M,Single fiber,20km,SC/ST/FC connector,external power supply
DW-MCS135-40 DW-MCS153-40	10/100M,Single fiber,40km,SC/ST/FC connector,external power supply
DW-MCS135-60 DW-MCS153-60	10/100M,Single fiber,60km,SC/ST/FC connector,external power supply
DW-MCS135-80 DW-MCS153-80	10/100M,Single fiber,80km,SC/ST/FC connector,external power supply
DW-MCS145-100 DW-MCS154-100	10/100M,Single fiber,100km,SC/ST/FC connector,external power supply
DW-MCS145-120 DW-MCS154-120	10/100M,Single Fiber,120km,SC/ST/FC connector,external power supply
