Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > GBIC-BX-D 1550TX 1310RX 3km 1000BASE-BX BIDI GBIC Module Transceiver

GBIC-BX-D 1550TX 1310RX 3km 1000BASE-BX BIDI GBIC Module Transceiver

Name: GBIC-BX-D 1550TX 1310RX 3km 1000BASE-BX BIDI GBIC Module Transceiver
Brand: DONGWE
SKU: 132176583

GBIC-BX-D 1550TX 1310RX 3km 1000BASE-BX BIDI GBIC Module Transceiver thumbnail-1

GBIC-BX-D 1550TX 1310RX 3km 1000BASE-BX BIDI GBIC Module Transceiver photo-1

US$ 1 - 20 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

DONGWE

Model Number:

DW-S1253-03CG

Contact Supplier Request Quote Chat Now

Shenzhen Dongwe Electronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Ningbo Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name DONGWE

Model Number DW-S1253-03CG

GBIC-BX-D 1550TX 1310RX 3km 1000BASE-BX BIDI GBIC Module Transceiver

Product Description

Features

¨ Dual data-rate of 1.25Gbps/1.0625Gbps operation

¨ 1550nm FP laser and PIN photodetector for 3km transmission

¨ Duplex SC optical interface

¨ Standard serial ID information compatible with SFF-8053

¨ +3.3V/5Vsingle power supply

¨ RoHS Compliant

¨ Operating case temperature: Standard : 0 to +70°C

Applications

¨ Switch to Switch interface

¨ Switched backplane applications

¨ Router/Server interface

¨ Other optical transmission systems

Product description

The GBIC transceiver is high performance, cost effective module supporting dual data-rate of 1.25Gbps/1.0625Gbps and from 3km transmission distance with SMF.

The transceiver consists of two sections: The transmitter section incorporates a FP laser. And the receiver section consists of a PIN photodiode integrated with a trans-impedance preamplifier (TIA). All odules satisfy class I laser safety requirements.

The optical output can be disabled by a TTL logic high-level input of Tx Disable. Tx Fault is provided to indicate degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver.

The standard serial ID information Compatible with GBIC MSA describes the transceiver’s capabilities, standard interfaces, manufacturer and other information. The host equipment can access this information via the two-wire serial CMOS EEPROM protocol. For further information, please refer to SFF-8053.

Optical and Electrical Characteristics

DW-S1253-03CG: (1550nm FP and PIN, 3km)

(Operating case temperature TC=25℃, VCC=3.3V)

Parameter		Symbol	Min.	Typical	Max.	Unit	Notes
Transmitter
Centre Wavelength		λC	1530	1550	1570	nm
Average Output Power		P0ut	-10		-4	dBm	1
Spectral Width (RMS)		σ			1	nm
Side Mode Suppression Ratio		SMSR	30
Extinction Ratio		ER	9
Output Optical Eye		IEEE 802.3z and ANSI Fibre Channel compatible					2
Data Input Swing Differential		VIN	300		1860	mV	3
Input Differential Impedance		ZIN	90	100	110	Ω
TX Disable	Disable		2.0		Vcc	V
TX Disable	Enable		0		0.8	V
TX Fault	Fault		2.0		Vcc+0.3	V
TX Fault	Normal		0		0.8	V
Receiver
Centre Wavelength		λC	1260		1360	nm
Receiver Sensitivity					-22	dBm	4
Receiver Overload			-3			dBm	4
Optical Path Penalty					1	dB	5
LOS De-Assert		LOSD			-23	dBm
LOS Assert		LOSA	-30			dBm
LOS Hysteresis			1		4	dB
Data Output Swing Differential		VOUT	370		1800	mV	6

Notes:

1. The optical power is launched into SMF.

2. Measured with a PRBS 2⁷-1 test pattern @1250Mbps.

3. PECL input, internally AC coupled and terminated.

4. Measured with a PRBS 2⁷-1 test pattern @1250Mbps, BER ≤1×10^-12.

5. Measured with a PRBS 2⁷-1 test pattern @1250Mbps, over 3km G.652 SMF, BER ≤1×10^-12.

6. Internally AC coupled.

Ordering Information

Part Number	Product Description
DW-T1000G	Copper GBIC, 1.25G, RJ45, 0°C~+70°C
DW-D1285-05CG	GBIC, 1.25G, 850nm, 550m, 0°C~+70°C
DW-D1231-20CG	GBIC, 1.25G, 1310nm, 20km, 0°C~+70°C
DW-D1231-40CG	GBIC, 1.25G, 1310nm, 40km, 0°C~+70°C
DW-D1255-80CG	GBIC, 1.25G, 1550nm, 80km, 0°C~+70°C

BIDI GBIC
DW-S1235-03CG	BIDI GBIC, 1.25G, 1310/1550nm, 3km, 0°C~+70°C
DW-S1253-03CG	BIDI GBIC, 1.25G, 1550/1310nm, 3km, 0°C~+70°C

DW-S1234-20CG	BIDI GBIC, 1.25G, 1310/1490nm, 20km, 0°C~+70°C
DW-S1243-20CG	BIDI GBIC, 1.25G, 1490/1310nm, 20km, 0°C~+70°C
DW-S1235-20CG	BIDI GBIC, 1.25G, 1310/1550nm, 20km, 0°C~+70°C
DW-S1253-20CG	BIDI GBIC, 1.25G, 1550/1310nm, 20km, 0°C~+70°C

DW-S1234-40CG	BIDI GBIC, 1.25G, 1310/1490nm, 40km, 0°C~+70°C
DW-S1243-40CG	BIDI GBIC, 1.25G, 1490/1310nm, 40km, 0°C~+70°C
DW-S1235-40CG	BIDI GBIC, 1.25G, 1310/1550nm, 40km, 0°C~+70°C
DW-S1253-40CG	BIDI GBIC, 1.25G, 1550/1310nm, 40km, 0°C~+70°C

CWDM GBIC
DW-D12CXX-40CG (XX=27~61)	CWDM GBIC, 1.25G, 1270~1610nm, 40km, 0°C~+70°C

DW-D12CXX-80CG (XX=27~61)	CWDM GBIC, 1.25G, 1270~1610nm, 80km, 0°C~+70°C
