GLC-2BX-D CSFP Module 1.25G Compact Bi-Di SFP Transceiver 10km Reach 1310nm TX / 1490nm RX SFP Module

GLC-2BX-D CSFP Module 1.25G Compact Bi-Di SFP Transceiver 10km Reach 1310nm TX / 1490nm RX SFP Module thumbnail-1
GLC-2BX-D CSFP Module 1.25G Compact Bi-Di SFP Transceiver 10km Reach 1310nm TX / 1490nm RX SFP Module photo-1
US$ 1 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DONGWE
Model Number:
DW-C1234-10C
Contact Supplier Request Quote Chat Now
Shenzhen Dongwe Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DONGWE
Model Number DW-C1234-10C

GLC-2BX-D, CSFP Module, 1.25G Compact Bi-Di SFP Transceiver, 10km Reach, 1310nm TX / 1490nm RX SFP Module

Product Description

 Features

  • Support 1.25Gbps data links
  • 1310nm FP laser and PIN photodetector for 10km transmission
  • 2xBi-directional transceivers in 1 SFP transceiver package
  • Compliant with CSFP MSA Option 2 and SFF-8472
  • Digital Diagnostic Monitoring: Internal Calibration or External Calibration
  • Compatible with SONET OC-3 system
  • Compatible with RoHS
  • +3.3V single power supply
  • Operating case temperature:0 to +70°C(Commercial) -40°C to +85°C (Industrial)

Applications

  • SONET OC-24 system
  • Fast Ethernet
  • Switch to Switch interface
  • Point to Point FTTH Application
  • Other optical transmission systems



Detail Description

The CSFP transceivers are high performance, cost effective modules supporting 1.25Gbps and 10km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with Compact SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.



Ordering Information



Part Number Product Description
155M CSFP BIDI
DW-C0334-02C(D) Compact SFP BIDI 155M 1310nm/1490nm 2km 0ºC ~ +70ºC (DDM)
DW-C0334-02T(D) Compact SFP BIDI 155M 1310nm/1490nm 2km -40ºC ~ +85ºC (DDM)

DW-C0334-10C(D) Compact SFP BIDI 155M 1310nm/1490nm 10km 0ºC ~ +70ºC (DDM)
DW-C0334-10T(D) Compact SFP BIDI 155M 1310nm/1490nm 10km -40ºC ~ +85ºC (DDM)

DW-C0334-20C(D) Compact SFP BIDI 155M 1310nm/1490nm 20km 0ºC ~ +70ºC (DDM)
DW-C0334-20T(D) Compact SFP BIDI 155M 1310nm/1490nm 20km -40ºC ~ +85ºC (DDM)

DW-C0335-02C(D) Compact SFP BIDI 155M 1310nm/1550nm 2km 0ºC ~ +70ºC (DDM)
DW-C0335-02T(D) Compact SFP BIDI 155M 1310nm/1550nm 2km -40ºC ~ +85ºC (DDM)

DW-C0335-10C(D) Compact SFP BIDI 155M 1310nm/1550nm 10km 0ºC ~ +70ºC (DDM)
DW-C0335-10T(D) Compact SFP BIDI 155M 1310nm/1550nm 10km -40ºC ~ +85ºC (DDM)

DW-C0335-20C(D) Compact SFP BIDI 155M 1310nm/1550nm 20km 0ºC ~ +70ºC (DDM)
DW-C0335-20T(D) Compact SFP BIDI 155M 1310nm/1550nm 20km -40ºC ~ +85ºC (DDM)

1.25G CSFP BIDI
DW-C1234-10C(D) Compact SFP BIDI 1.25G 1310nm/1490nm 10km 0ºC ~ +70ºC (DDM)
DW-C1234-10T(D) Compact SFP BIDI 1.25G 1310nm/1490nm 10km -40ºC ~ +85ºC (DDM)

DW-C1234-20C(D) Compact SFP BIDI 1.25G 1310nm/1490nm 20km 0ºC ~ +70ºC (DDM)
DW-C1234-20T(D) Compact SFP BIDI 1.25G 1310nm/1490nm 20km -40ºC ~ +85ºC (DDM)

DW-C1235-20C(D) Compact SFP BIDI 1.25G 1310nm/1550nm 20km 0ºC ~ +70ºC (DDM)
DW-C1235-20T(D)         Compact SFP BIDI 1.25G 1310nm/1550nm 20km -40ºC ~ +85ºC (DDM)
