Home > Computer Products > Network Hardware & Parts > Network Switch > 16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output

16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output

Henan Yinet Communications Co., Ltd.
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output thumbnail-1
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output thumbnail-2
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output thumbnail-3
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output thumbnail-4
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output thumbnail-5
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output photo-1
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output photo-2
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output photo-3
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output photo-4
16 Port PoE POE Switch With 4*giga SFP/TX Combo Port 802.3af/at 48V Poe Output photo-5
US$ 180 - 190 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
24
Transmission Rate:
10/100Mbps
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports 24
Transmission Rate 10/100Mbps
Function POE
Communication Mode Other, Full-Duplex & Half-Duplex
Certification ISO
Switch Capacity 12.8Gbps
Brand Name YI NET
Model Number TS2416FI
Place of Origin Henan, China

16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output



Introduction

TS2416FI is applied to POE IPC camera, POE WIFI AP, and POE IPPHONE, and easy for network transmission. This device comes with SFP port, easy for optical fiber remote transmission.



Main Features

 16FE POE+4GE+4 COMBO SFP.

 Comply to IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,802.3X,802.3z.

 Comply to POE IEEE 802.3af/at standard, all ports standard testing.

 Support POE IPC camera, POE WIFI AP, and POE IPPHONE.

 Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.

 Auto MDI/MDIX.

 Upstream port lightning protection.

 MAX 30W, MAX power 150W.

 Store-and-forward.

 All ports support wire speed switch, jumbo frame transmission.

 Zero QFD, self-adaption.

 Panel lights can monitor operative mode and malfunction analysis.



Specification

Model

TS2416FI



ElectricPort

100M POE

16

1000M Rj45

4

SFP

4





 Function

Exchange

Mechanism

Store-and-forward

Exchange Capacity

12.8G

MAC

16K



Environmental

Working Temperature:0-40

Storage temperature :-40-70

Working Tumidity :10%-90% RH non-condensing

Storage temperature:5%-90% RH non-condensing

POE

IEEE802.3af/at, MAX 30W, MAX power 300W

power

AC110-265V 50/60HZ 2.5A





Network protocol

IEEE 802.3X

IEEE 802.3i 10BASE-T X

IEEE 802.3u 100BASE-TX

IEEE 802.3z 1000BASE-X G

IEEE 802.3af /IEEE 802.3at

IEEE 802.3x Flow control

IEEE 802.1q VLAN Bridge operation

Default

Mode

Common switch

Match

VLAN isolation



Speed

Ethernet 10Mbps half-duplex, 20Mbps full-duplex

Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex

Gigabit Ethernet 2000Mbps full-duplex





Network Media

10Base-T: Pair 2 Category 3 and above UTP/STP(≤100m)

100Base-TX: Pair 2 Category 5 and above UTP/STP(≤100m)

1000Base-T: Pair 4 Category 5 and above UTP/STP(≤100m)

1000Base-SX:62.5μm/50μm MMF(2m~550m)

1000Base-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)

Physical Specifications

Product Size:440mm*290mm*45mm(L*W*H)

package Size:497mm*393mm*97mm(L*W*H)

4.5kg



Product Ordering Information :

Model Number:TS2416FI

Product Details:16FE POE+4GE+4 COMBO SFP

16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output



16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output

16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output

16 Port PoE POE Switch with 4*giga SFP/TX combo port 802.3af/at 48V poe output

.

FAQ

1.What is the warranty on the parts you sell?

All parts sold by YINET meet all of the manufactures specifications and carry one year warranty. Some customized products could carry up to three years warranty.

2.How to repair a broken product?such as POE switch,wireless router and Ethernet switch products

Usually we supply free substitute model for the small value products. and we bear the freight. For Big-ticket items or high value products,Considering the high freight and cost we can supply free parts such as PCBA,power adapter or power supply etc. We can also provide remote guidance.

3.What payment methods do you offer?

We accept payment via T/T, L/C,Western Union, MoneyGram and PayPal;

4. What is your minimum order?
To achieve customers' satisfaction, we accept sample order, even one Piece.
