24 Port 10/100/1000Mbps Managed Network Switch With 2 Giga SFP Fiber Port

24 Port 10/100/1000Mbps Managed Network Switch With 2 Giga SFP Fiber Port thumbnail-1
24 Port 10/100/1000Mbps Managed Network Switch With 2 Giga SFP Fiber Port photo-1
US$ 150 - 190 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
24
Transmission Rate:
10/100/1000Mbps
Contact Supplier Request Quote Chat Now
Henan Yinet Communications Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports 24
Transmission Rate 10/100/1000Mbps
Function LACP, VLAN Support
Communication Mode Other, Full-Duplex & Half-Duplex
Certification ISO
Switch Capacity 52Gbps
Brand Name YI NET
Model Number S3500-26G-2F
Place of Origin Guangdong, China

S3500 series full gigabit managed Ethernet switch

S3500 Series L2 Managed Switches. The S3500 series enterprise switches are Full Gigabit L2 switches. The S3500 provides high-performance access and aggregation to an enterprise campus network. The S3500 series switches integrates many advanced technologies in terms of reliability, security, and energy saving. It employs simple and convenient means of installation and maintenance to reduce customers' OAM cost and help enterprise customers build a next-generation IT network.



Comprehensive QoS policies and security mechanisms

The S3500 classifies complex traffic based on packet information such as the 5-tuple, IP preference,ToS, DSCP, IP protocol type, ICMP type, and QoS. Each port supports eight priority queues and multiple queue scheduling algorithms, such as WRR, SP, WRR+SP. Together, these features ensure high-quality voice, video, and data services.

The S3500 provides multiple security measures to defend against Denial of Service (DoS) attacks, as well as attacks against networks or individual users. DoS attack types include SYN Flood attacks, Land attacks,Smurf attacks, and ICMP Flood attacks. Attacks on networks refer to STP BPDU/root attacks. Attacks on users include bogus DHCP server attacks, man-in-the-middle attacks, IP/MAC spoofing attacks, and DHCP request flood attacks. DoS attacks that change the CHADDR field in DHCP packets are another type of attack aimed at users.



Powerful support for services

The S3500 supports IGMP v1/v2/v3 snooping, IGMP filter, IGMP fast leave, and IGMP proxy. The S3500 supports wire-speed replication of multicast packets between VLANs, multicast load balancing among member interfaces of a trunk, and controllable multicast, meeting requirements for IPTV and other multicast services.



Energy conservation, and low radiation

The S3500 uses an energy-saving integrated circuit design to ensure even heat dissipation. Idle ports can enter a sleep mode to further reduce power consumption. Radiation produced by the S3500 is within the standard range for electric appliances and causes no harm to the human body.



Easy deployment and maintenance free

Supports SNMP v1/v2c and provides flexible methods for managing devices. Users can manage the S3500 using the CLI and Web NMS.



Hardware specs



Items

S3500-26G-2F

S3500-10G-2F

Fixed port

24*10/100/1000 Base-T ports

8*10/100/1000 Base-T ports

2*1000 Base-X SFP ports

2*1000 Base-X SFP ports

1*Console port

Switching Capacity

≥52Gbps

≥20Gbps

Packet Forwarding Capacity

39Mpps

15Mpps

Operating environment

Operating temperature: 0℃–50℃

Relative humidity: 5%–95% (non-condensing)

Dimensions

440(L)×285(W)×44.5(H)mm

280(L)*180(W)*44(H)mm

Weight

<4Kg

<2Kg

Input Voltage

AC:110~240V/50~60Hz

Power Consumption

<30W

<10W


Software specs






Item

S3500-26G-2F

S3500-10G-2F

Standards

IEEE 802.3ad, Link Aggregation

IEEE 802.3,10BASE-T

IEEE 802.3u,100 BASE-TX

IEEE 802.3ab,1000 BASE-T

IEEE 802.3z,1000 BASE-X

IEEE 802.3x, Ethernet flow control

IEEE 802.3az,EEE(Energy Efficient Ethernet)

IEEE 802.1AB-2005,LLDP( Link Layer Discovery Protocol)

IEEE 802.1d, Spanning Tree Protocol

IEEE 802.1w, Rapid Spanning Tree Protocol

IEEE 802.1q, VLAN

IEEE 802.1p,QoS

MAC Address

8K MAC addresses

MAC address learning and aging

VLAN

4K VLANs

Port-based VLANs

Voice VLAN

Spanning Tree

STP(Spanning Tree Protocol)

RSTP( Rapid Spanning Tree Protocol)

Link Aggregation

Max 8 aggregation groups, each supports 8 ports

Static aggregation and dynamic aggregation

Port Mirroring

Many-to-one port mirroring

Multicast

IGMP v1/v2/v3 snooping and IGMP fast leave

QoS

Rate limiting on packets sent and received by an interface

Eight queues on each port

WRR, SP, WRR+SP queue scheduling algorithms

Re-marking of the 802.1p priority and DSCP priority

Rate limiting in each queue and traffic shaping on ports

Security

DoS attack defense, ARP attack defense, and ICMP attack defense

Port isolation

User privilege management and password protection

Management and maintenance

SNMP v1/v2c

Remote configuration and maintenance using Telnet

Web NMS

System logs and alarms of different levels
