Ethernet switch 8 Port full gigabit 10/100/1000Mbps desktop network switch
Introduction
SW0800G supply 8 port 10/100/1000Mbps RJ45 port,metal housing and desktop network switch. It can be applied to IPC camera, Wireless AP, and IP Phone, and easy for network transmission.
Main Features
8GE.
Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3ab.
Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.
Auto MDI/MDIX.
Upstream port lightning protection.
Store-and-forward.
All ports support wire speed switch, jumbo frame transmission.
Zero QFD, self-adaption.
Panel lights can monitor operative mode and malfunction analysis.
Specification
Model |
SW0800G |
|
1000M Rj45 |
8 |
|
|
Function |
Exchange Mechanism |
Store-and-forward |
Exchange Capacity |
16G |
|
MAC |
4K |
|
|
Environmental |
Working Temperature:0℃~40℃ Storage temperature :-40℃~70℃ |
|
|
Working Humidity :10%~90% RH non-condensing Storage Humidity:5%~90% RH non-condensing | ||
power |
DC 12V 1A |
|
|
Network protocol |
IEEE 802.3X IEEE 802.3i 10BASE-T X IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T G IEEE 802.3x Flow control IEEE 802.1q VLAN Bridge operation |
|
|
Default Mode |
Common switch |
|
Match |
VLAN isolation |
|
|
Speed |
Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex |
|
|
Network Media |
10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) 1000Base-T: Pair 4 Category 5 (cat 5e)and above UTP/STP(≤100m) |
|
Physical Specifications |
Product Size:175mm*75mm*30mm(L*W*H) 0.5Kg |
|
Product Ordering Information :
Model Number:SW0800G
Product Details:8GE
Porduct Photo
FAQ
1.What is the warranty on the parts you sell?
All parts sold by YINET meet all of the manufactures specifications and carry one year warranty. Some customized products could carry up to three years warranty.
2.How to repair a broken product?such as POE switch,wireless router and Ethernet switch products
Usually we supply free substitute model for the small value products. and we bear the freight. For Big-ticket items or high value products,Considering the high freight and cost we can supply free parts such as PCBA,power adapter or power supply etc. We can also provide remote guidance.
3.What payment methods do you offer?
We accept payment via T/T, L/C,Western Union, MoneyGram and PayPal;
4. What is your minimum order?
To achieve customers' satisfaction, we accept sample order, even one Piece.
