Ironclad 12V8.5A,15V7A,24V4.5A,28V3.6A,36V2.8A,48V2.3A Switching Power Supply

Name: Ironclad 12V8.5A,15V7A,24V4.5A,28V3.6A,36V2.8A,48V2.3A Switching Power Supply
Brand: OBSUN
SKU: 132148509

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

OBSUN

Model Number:

xxxyyy

Shenzhen Aobosen Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name OBSUN

Model Number xxxyyy

Output Power 51 - 100W

Output Type Single

Input Voltage Other, AC90V---264V

Output Voltage 3.3V-48V

Output Frequency 50/60Hz

Output Current 2.3A-20A

Specifications

Switching power supply
1.High power and low power consumption
2.full tested before shipping
3.Long cycle life

Switching power supply

Product Electric Parameters
Input specification	Input voltage		AC90V---264V
	Input frequency		47-63Hz
	Input surge		20A@120VAC 40A@230VAC
Output specification	Output voltage can be adjusted		±10%
	Start-up time		leq1S(input230V Io=100%)
	keep time		more than or equal to 20mS (input230V,Io=100%)
	Voltage regulation		(Full load) leq0.5%
Protection function	Overload protection		105% - 150% rated power, automatic recovery
	Over-voltage protection		105% - 150% of the rated voltage
Insulation intensity	Input---output		1500VAC/1min
	Input---ground		1500VAC/1min
	Input---ground		500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards	According with GB9254, EN55022 class A
Environmental	working temperature	- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature	- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level	leq2000M
Structure	Size (mm)	199(L)98(W)38(H)
Cooling method	Cooling method	Natural cooling air convection
Weight	0.56KG/PCS
Product Type Table
Product model	output specification		ripple, noise	efficiency
S-100-3.3	3.3V	20A	50mV	66%
S-100-5	5V	20A	50mV	76%
S-100-9	9V	11A	70mV	78%
S-100-12	12V	8.5A	100mV	80%
S-100-15	15V	7A	100mV	80%
S-100-24	24V	4.5A	100mV	80%
S-100-28	28V	3.6A	100mV	80%
S-100-36	36V	2.8A	200mV	80%
S-100-48	48V	2.3A	240mV	82%
