Stainless Steel Cable Tie /Ball-Lock Tie
Features:
Manufactured from type #304,#316 stainless steel material, the ball lock tie unique buckle design is fast becoming the globally accepted industry standard.
1. Four widths-0.18 (4.6mm), 0.31 (7.9mm), 0.47 (12mm) and 0.59 (15mm) for applications ranging from identification tagging to bund large cables.
2. Self locking design allows fast installation.
3. Installation by hand or with tools to assure uniform tension and clean tail cut-off for safe handing-Available in type 304 and type 316 stainless steel to provide good to excellent corrosion resistance in wide variety of environments.
4. Coated ball lock ties are fully coated with black epoxy normal. It also can be done in colorful type.
Application:
Corrosion resistance is ideal for harsh marine environments. It's used in cable management applications to reduce the risk of cutting or abrading cable.
As the stainless steel band is inserted into the buckle, the internal locking ball rolls freely. During tensioning, the band wedges into the buckle locking ti tightly between the buckle and the band.
Data Sheet:
| Item No. | Length | Width | Maximum Bundle Diameter | Packaging | |||
| Inch | MM | Inch | MM | Inch | MM | Pcs/Bag | |
| CTS-100 | 4" | 100 | 0.18 | 4.6 | 1" | 25 | 100 |
| CTS-150 | 6" | 150 | 0.18 | 4.6 | 1.5" | 39 | 100 |
| CTS-200 | 8" | 200 | 0.18 | 4.6 | 2" | 50 | 100 |
| CTS-360 | 14" | 360 | 0.18 | 4.6 | 4" | 100 | 100 |
| CTS-520 | 20.5" | 520 | 0.18 | 4.6 | 6" | 150 | 100 |
| CTS-680 | 26.5" | 680 | 0.18 | 4.6 | 8" | 200 | 100 |
| CTS-840 | 33" | 840 | 0.18 | 4.6 | 10" | 250 | 100 |
| CTS-1000 | 39" | 1000 | 0.18 | 4.6 | 12" | 300 | 100 |
| CTM-200 | 8" | 200 | 0.31 | 7.9 | 2" | 50 | 100 |
| CTM-360 | 14" | 360 | 0.31 | 7.9 | 4" | 100 | 100 |
| CTM-520 | 20.5" | 520 | 0.31 | 7.9 | 6" | 150 | 100 |
| CTM-680 | 26.5" | 680 | 0.31 | 7.9 | 8" | 200 | 100 |
| CTM-840 | 33" | 840 | 0.31 | 7.9 | 10" | 250 | 100 |
| CTM-1000 | 39" | 1000 | 0.31 | 7.9 | 12" | 300 | 100 |
| CTM-1200 | 47" | 1200 | 0.31 | 7.9 | 14" | 365 | 100 |
| CTM-1400 | 55" | 1400 | 0.31 | 7.9 | 17" | 425 | 100 |
| CTL-200 | 8" | 200 | 1/2" | 12 | 2" | 50 | 100 |
| CTL-290 | 11.5" | 290 | 1/2" | 12 | 3.1" | 80 | 100 |
| CTL-360 | 14" | 360 | 1/2" | 12 | 3.9" | 100 | 100 |
| CTL-520 | 20.5" | 520 | 1/2" | 12 | 5.9" | 150 | 100 |
| CTL-680 | 26.5" | 680 | 1/2" | 12 | 7.9" | 200 | 100 |
| CTL-840 | 33" | 840 | 1/2" | 12 | 9.8" | 250 | 100 |
| CTL-1000 | 39" | 1000 | 1/2" | 12 | 11.8" | 300 | 100 |
Package of stainless steel cable tie:
A. Common Packing: 100 Pcs +Polybag+ Label + Export Carton
B. Common Packing:Colorful Inner Box + Export Carton
C. Customized Packing: OEM Label, Inner Box, Blister, etc.
