Cable Binder,Kabel Binder
Specifications
1. UL listed2. Free Samples
3. Fast Delivery
4. High Quality Packing Style
5. International Standard Specification
Description of Cable Tie: s,nylon cable ties,nylon cable ties,nylon cable ties,nylon cable ties
A cable tie, also known as a zip tie or tie-wrap, is a type of fastener, especially for binding several electronic cables or wires together and to organize cables and wires.
- Material: Nylon 66, 94V-2 certificated by UL. Heat-resisting, Acid & erosion control, insulated well an not apt to age.
- Operation temperature: -35°c to 80°c.
- Characteristics: 94V-2
- Packing: High Quality Packing Style: 100 natural packing and as requested.
- Payment: T/T, L/C
- Color: Natural(or white, standard color), UV Black and other colors are available as request.
Diagrammatic Drawing of Cable Tie:
| Part No.: | Length(L) | Width(W) | Bundle Diameter(E) | Tensile Strength | |||
| Inch | MM | MM | MM | LBS | KGS | ||
| CT-2.5×60 | 2.4" | 60 | 2.5 | 2-11 | 18 | 8 | |
| CT- 2.5*80 | 3.2" | 80 | 2-16 | ||||
| CT- 2.5*100 | 4.0" | 100 | 2-22 | ||||
| CT- 2.5*120 | 4.7" | 120 | 2-30 | ||||
| CT- 2.5*150 | 6.0" | 150 | 2-35 | ||||
| CT- 2.5*160 | 6.3" | 160 | 2-40 | ||||
| CT- 2.5*200 | 8.0" | 200 | 3-50 | ||||
| CT- 3.6*140 | 5.5" | 140 | 3.6 | 3-33 | 40 | 18 | |
| CT- 3.6*150 | 6.0" | 150 | 3-35 | ||||
| CT- 3.6*250 | 10.0" | 250 | 3-65 | ||||
| CT- 3.6*280 | 11.0" | 280 | 3-70 | ||||
| CT- 3.6*300 | 12.0" | 300 | 3-80 | ||||
| CT- 3.6*370 | 14.6" | 370 | 3-105 | ||||
| CT- 4.8*120 | 4.7" | 120 | 4.8 | 3-30 | 50 | 22 | |
| CT- 4.8*160 | 6.3" | 160 | 3-40 | ||||
| CT- 4.8*180 | 7.1" | 180 | 3-42 | ||||
| CT- 4.8*190 | 7.5" | 190 | 3-46 | ||||
| CT- 4.8*200 | 8.0" | 200 | 3-50 | ||||
| CT- 4.8*250 | 10.0" | 250 | 3-65 | ||||
| CT- 4.8*280 | 11.0" | 280 | 3-70 | ||||
| CT- 4.8*300 | 12.0" | 300 | 3-80 | ||||
| CT- 4.8*350 | 14.0" | 350 | 3-90 | ||||
| CT- 4.8*360 | 14.2" | 360 | 3-94 | ||||
| CT- 4.8*370 | 14.6" | 370 | 3-98 | ||||
| CT- 4.8*380 | 15.0" | 380 | 3-102 | ||||
| CT- 4.8*400 | 16.0" | 400 | 3-105 | ||||
| CT- 4.8*430 | 16.9" | 430 | 3-120 | ||||
| CT- 4.8*450 | 17.7" | 450 | 3-130 | ||||
| CT- 4.8*500 | 19.7" | 500 | 3-150 | ||||
| CT- 7.2*150 | 6.0" | 150 | 7.2 | 3-35 | 120 | 55 | |
| CT- 7.2*200 | 8.0" | 200 | 3-50 | ||||
| CT- 7.2*250 | 10.0" | 250 | 4-65 | ||||
| CT- 7.2*280 | 11.0" | 280 | 4-78 | ||||
| CT- 7.2*300 | 12.0" | 300 | 4-80 | ||||
| CT- 7.2*350 | 14.0" | 350 | 4-90 | ||||
| CT- 7.2*370 | 14.6" | 370 | 4-98 | ||||
| CT- 7.2*380 | 15.0" | 380 | 4-100 | ||||
| CT- 7.2*400 | 16.0" | 400 | 4-105 | ||||
| CT- 7.2*450 | 18.0" | 450 | 4-110 | ||||
| CT- 7.2*500 | 20.0" | 500 | 4-150 | ||||
| CT- 7.2*530 | 20.9" | 530 | 4-160 | ||||
| CT- 7.2*550 | 21.6" | 550 | 4-165 | ||||
| CT- 9.0*400 | 16.0" | 400 | 9.6 | 8-105 | 175 | 80 | |
| CT- 9.0*450 | 18.0" | 450 | 8-118 | ||||
| CT- 9.0*500 | 20.0" | 500 | 1-150 | ||||
| CT- 9.0*550 | 21.6" | 550 | 8-160 | ||||
| CT- 9.0*600 | 23.6" | 600 | 8-170 | ||||
| CT- 9.0*650 | 25.6" | 650 | 8-185 | ||||
| CT- 9.0*720 | 28.3" | 720 | 10-195 | ||||
| CT- 9.0*800 | 31.5" | 800 | 10-230 | ||||
| CT- 9.0*900 | 35.5" | 900 | 10-265 | ||||
| CT- 9.0*1000 | 29.4" | 1000 | 10-300 | ||||
| CT- 9.0*1100 | 43.3" | 1100 | 10-335 | ||||
| CT- 9.0*1200 | 47.2" | 1200 | 10-370 | ||||
| CT- 12**650 | 25.6" | 650 | 12 | 14-185 | 250 | 114 | |
| CT- 12*900 | 25.5" | 900 | 14-265 | ||||
Certificate of round plastic wire tie :
ble
Package of round plastic wire tie:
A. Common Packing: 100Pcs + Polybag + Label + Export Carton
B. Customized Packing: Header card packing, Blister with card packing, Double blister packing, Canister packing, other packing can be supplied according customers request.
Delivery of round plastic wire tie: ties nylon cable ties nylon cable ties nylon cable ties nylon cable ties
A.By Courier: 4-7 Working days by special offer
B.By Air: 7 Working days at appointed airport
C.By Sea: 20-25 Working days at appointed port
