Product Details
| Condition | New | Type | Fabric Dust Collector | |
| Efficiency | 6500~15000 | Minimum Particle Size | 0.3 micro meters | |
| Place of Origin | Shandong, China | Brand Name | powerful | |
| Model Number | FD601~FD691 | Dimension(L*W*H) | 1500*1500*2600 | |
| Weight | 500KG~2000KG | Certification | ISO9001 | |
| Warranty | WHOLE USAGE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.powerful dust collecting ability, high cleaning efficiency,2.low exhausting density, small wind leakage, low energy
Established in the year of 2007, 129 employees in our company, 5 technical experts, We are expert at manufacturing DUST COLLECTOR, METAL MOULDING MACHINE, and SHOT BLASTING MACHINE.Our business has expanded to mid-easten countries, Africa, Russia, South-east Asia, south American countries as well, we have built up a long-term stable and mutual trust business relationship with our customers. We can offer our clients reasonable quotation, guarantee our customers best quality and best service among our competitors in China.
Puls Filter Bag type Dust Collector
Technical parameter
| type | Dedustsing air volume(m3/h) | Dimesnion of filter bag(dia*Lmm) |
| BHMC24 | 5000 | 125X2600mm |
| BHMC36 | 7500 | 125x2600mm |
| BHMC48 | 10000 | 125x2600mm |
| BHMC64 | 12000 | 125x2600mm |
| BHMC72 | 15000 | 125x2600mm |
| BHMC108 | 20000 | 125x2600mm |
| BHMC160 | 27000 | 125x2600mm |
How to choose a suitable type of dust collector
* Filtered area(m2)
* Air flow(Q)
* Temperature
* Density of intake dusty air
* Density of outlet dust
* Pressure loss
* Operating pressure
* Filtering speed(m/min)
* Filter bag’s length-diameter ratio
* Acid-base property of smog air
Adapting area
carpentry workshop, paint shop, polishing workshop, battery workshop, chemical plant, cement plant, coal mine, power plant.
Techincal parameters of shaker dust collector
| Type | Dedusting air flow volume(m3/h) | Filter bag(diaxL mm) |
| FBD-16 | 2200 | 125x1300 |
| FBD-20 | 2800 | 125x1300 |
| FBD-24 | 3500 | 125x1300 |
| FBD-30 | 5200 | 125x1300 |
| FBD-24a | 9000 | 170x1900 |
| FBD-30a | 10500 | 170x1900 |
| FBD-36 | 11000 | 170x1900 |
| FBD-48 | 12000 | 170x1900 |
| FBD-60 | 16000 | 170x1900 |
| FBD-72 | 18000 | 170x1900 |
| FBD-96 | 25000 | 170x1900 |
Technical parameters of Filter Catridge dust collector
| Type | Dedusting air flow volume(m3/h) | Flitered area(m3) | Fan power(KW) |
| HR-4 | 3000 | 60 | 5.5 |
| HR-8 | 6000 | 120 | 7.5 |
| HR-12 | 9000 | 180 | 11 |
| HR-16 | 12000 | 240 | 22 |
| HR-24 | 18000 | 360 | 22 |
| HR-32 | 24000 | 480 | 30 |
| HR-36 | 27000 | 540 | 37 |
| HR-40 | 30000 | 600 | 37 |
| HR-48 | 36000 | 720 | 37 |
| HR-56 | 42000 | 840 | 45 |
| HR-64 | 56000 | 860 | 45 |
Specification of Compressed air type dust collector
| Tyep | Bag quantity | Filtering area | width(mm) | air volume(m3/h) |
| FD601 | 72 | 108 | 1150 | 6500~13000 |
| FD610 | 108 | 162 | 1630 | 9700~19500 |
| FD602 | 144 | 210 | 2198 | 13000~26000 |
| FD611 | 180 | 270 | 2678 | 16500~32500 |
| FD620 | 216 | 324 | 3158 | 19500~39000 |
| FD612 | 252 | 378 | 3726 | 22700~45400 |
| FD621 | 288 | 432 | 4206 | 26000~52000 |
| FD630 | 324 | 486 | 4686 | 30000~60000 |
| FD622 | 360 | 540 | 5254 | 33000~66000 |
