Bio Burner
- 50 Set / Sets per Month
- Qingdao
- Turkey Suspended Mantel TV Stand Wall Parts Sets Fireplaces
- Inserts Tools Pellet Decor Flame Stoves Modern Decorative Cast Iron Fireplaces
- Artificial Screens Table Indoor Garden Modern Glass Surround Mist Cast Iron Fireplaces
- Sale Decoration Vintage Stone Terrace Floor Vertical Heaters Luxury Cast Iron Fireplaces
- Stone Cheap TV Stand Home Smart Living Room Pellet Cast Iron Fireplaces
- Ecological Bellows Classical Tall Dark Built Simple Electric Patio Fireplaces
Product Details
Place of Origin: | Shandong, China | Brand Name: | LEADING | Model Number: | HR-45-FL |
Usage: | Outdoor | Function: | With Remote Control | Type: | Pellet Fireplaces |
Installation Type: | Freestanding |
Product Description
HR series Burner adopts half gasification suspension combustion technology, with reasonable structure, PLC operating system, automatic intelligent operation, touch screen, one key in both English and Chinese LCD interface, fully sealed frequency control of motor speed feed, with 485 operation interface, remote automatic ignition, automatic temperature control, the size of the fire automatic conversion. With double frequency conversion to air supply, feeding frequency synchronization, high thermal efficiency, burning full, still can reduce the discharge crater dust. Double after double control, can control temperature low (high stop) also can control the boiler pressure
No pollution, low emission, compact structure, simple installation, convenient, small footprint, low running cost, etc. To satisfy different customers to use, make full use of heat energy, USES air-cooled, water-cooled two protection, air combustion, the flame temperature is more strong. Water-cooled structure, hot water is produced to do production and living water, can also be received secondary use of the boiler, make full use of the heat source.
1. High efficiency and energy saving: with renewable biomass pellet fuel for energy, use cost low, than fuel (gas) by 30% - 60% of the cost
2. High thermal efficiency, half gasification suspension combustion and the tangent of swirling air distribution design, section at low temperature burning, burning rate is above 98%, furnace temperature is above 1200 ℃
3. Stable and reliable: micro positive pressure operation, the isolation of silo feeding way, without tempering and fire off phenomenon, has applied for national invention patent.
4. Low carbon environmental protection: ash, low sulfur and nitrogen emissions, near zero carbon dioxide emissions, meet GB12371 soot emission requirements.
5. The operation is simple, easy installation, automatic feeding, simple operation, small workload, great capacity of bin (customizable large capacity storage bin), charging can run 3-12 hours at a time, just fill it up with timely bin, single person on duty.Application: widely applied in the spray drying line; Aluminum processing, casting, heat treatment, annealing furnace, heating furnace, molten aluminum bar furnace; Industrial furnaces; Greenhouses; Steam boiler, hot water boiler, heat conduction oil boiler, hot-blast stove; Drying equipment; Paint, wood, sandstone, leather, clothing, ceramics, paper, food drying equipment and other heating equipment matching and energy saving transformation.
Model | Heat output Kilocalorie | Power (kw) | Material Consumption(kg) | Flame center distance(mm) | Flame dia(mm) | External size (mm) | Cooling way |
HR-20-FL | 200,000 | 1.1 | 15-40 | 630 | 135 | 1650*500*1360 | Wind cooling |
HR-30-FL | 300,000 | 1.5 | 20-70 | 680 | 135 | 1650*500*1500 | |
HR-45-FL | 450,000 | 1.9 | 25-120 | 830 | 170 | 1650*620*1700 | |
HR-60-FL | 600,000 | 2.5 | 40-170 | 930 | 170 | 2000*700*1850 | |
HR-60-FL-1.0 | 600,000 | 2.5 | 40-170 | 930 | 170 | 2000*700*1850 | Water cooling |
HR-60-FL-1.5 | 900,000 | 2.6 | 60-240 | 930 | 170 | 2100*800*1880 | |
HR-60-FL-2.0 | 1,200,000 | 3 | 80-350 | 1050 | 260 | 2800*1000*2300 | |
HR-60-FL-3.0 | 1,800,000 | 5.5 | 100-550 | 1150 | 260 | 3200*1200*2500 | |
HR-60-FL-4.0 | 2,400,000 | 7.5 | 130-700 | 1150 | 325 |
| |
HR-60-FL-5.0 | 3,000,000 | 11 | 150-900 | 1250 | 325 |
|
Comments: Fuel consumption with calorific value of 4200 kcal/h, the density of 1.1 1.4 wooden biomass pellet fuel testing, fuel consumption, depending on the temperature.
The offensive reference parameters, the company reserves the rights of technical change.
