PE Construction Formwork (Plastic Formwork)

Specifications

1)PE Construction Formwork thickness:8-20mm
2)High quality with competitive price
3)Long life
4)Can be recycled

Welcome to visit our PE Construction Formwork!

PE Construction Formwork is made of PE PP, fly ash, calcium carbonate and other fillers.



It is 5 layers, as the picture, outside two green surfaces are PP or PE, using the recycling material, such as the recycled film, package, the reclaimed plastic pipe, barrel and other things!

In the middle it is made by the fly ash, calcium carbonate and the other fillers.



And there are two layer fiberglass net in it!  It made the board have the high intensity, small distortion degree and small expansion coefficient.



The plastic building templates can replace steel templates and bamboo plastic sheet templates. Its advantages are as follows: low cost, light weight, it can continuous use 20 -50 times, Waste material can be re-used to do new building templates!



In the following it is some test result, you can see!



NO.	Item	Unit	Result	Standard
01	Tensile strength  portrait	Mpa	13.4	GB/T1040.2-2006/1B/10
02	Water absorption	g/m²	2.3	GB/T1034-1998
03	Shore hardness	HD	60	GB/T2411-1980
04	Vicat softening hardness  A50	°C	124	GB/T1633-2000
05	Simple support Impact strength portrait I type test sample	KJ/m²	9.3	GB/T1043-1993
06	Flexural strength   portrait V=5mm/min	Mpa	20.5	GB/T9341-2000
07	Modulus of elasticity in static bending   portrait V=2mm/min	Mpa	2080	GB/T9341-2000
08	Retraction ratio 135°C 2h length and breadth	%	0.18/0.22



The advantages of the five-layer formwork are as follows:



Compared with the traditional formwork, our five-layer formwork has the following advantages:



1. Good water resistance. Even if it completely immersed in water for several days, it will not damp deformation, rust will not rot.



2. Incompatible with the cement, not adhesion, mold release easily after construction, it will not cement the adhesion and deformation.



3. Construction of high efficiency and good quality. Construction of the building with its smooth surface, no secondary modification, saving process, improve construction efficiency.



4. Light weight, convenient construction.



5. Long life, re-use more often. Ultimately the damaged plastic formwork can be crushed again, re-processed into a new formwork, save resources, meet the "green industry" requirement.



6. Insulation is good, beneficial to shorten the construction period.



7. It has the acid and alkali proof, corrosion proof, weather-resistant, anti-aging, long service life. It can be sawing, planing, nailing, drilling, riveting as the wood, also can be painted and carved. By virtue of its superior performance, it can completely replace the wood and steel construction forwork. Can be widely used in indoor and outdoor construction formwork, mobile homes, board and train box compartment partitions, ships and so on.

.
