Sign Board Aluminum Composite Panel for Digital Printing

Name: Sign Board Aluminum Composite Panel for Digital Printing
Brand: Sunshine
Availability: InStock

FOB Price

US$ 2 - 20 / Meter

1000 Meters(Min. Order)

Port QINGDAO
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Sunshine
Model Number	Aluminum Honeycomb Panel	Usage	Outdoor
Function	Anti-Static, Antibacterial, Fireproof, Mould-Proof	Surface Treatment	Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated

Product Description

Aluminum Composite Panel is a composite material made of aluminum and non-combustible mineral filled core. Though the core material does contain a small amount of combustible polyethylene, the main ingredient of the non-combustible mineral filled core does not permit the proliferation of flame and restricts smoke. It is a fire-safe material that passes mandatory requirements for exterior and interior application.It is an ideal material for external claddings, roof of pedestrian passage and other architectural applications.

Aluminium Composite Panel (ACP) or Aluminium Composite Material (ACM) is a widely-used term describing flat panels that consist of a non-aluminium core bonded between two aluminium sheets. Aluminium sheets can be coated with PVDF or Polyester paint. ACPs are frequently used for external cladding of buildings (building facades), for insulation and for signage.

Materials:

1) Front side: aluminum roll coated with PVDF orPE
2) Core: plastic/ fireproof materials
3) Rear side: aluminum or aluminum coated with polyester

Specification

Aluminum alloy : AA1100, AA3003

Aluminum skin thickness: 0.04mm /0.06mm /0.08mm/0.12mm/0.15mm/0.18mm/ 0.21mm/0.30mm 0.35mm / 0.40mm / 0.45mm / 0.50mm

Surface coating : POLYESTER, PVDF, EMBOSSED POLYESTER
Middle core: recycle PE / fireproof core B1/A2

Panel thickness: 2-6mm

Width:1000mm, 1220mm, 1250mm, 1500mm,1600mm,2000mm
Length: 2440mm till 6000mm

Color: Matt, Glossy, Metalic series, Factory standard, RAL color chart

Special size and colors can be customized.

Characteristics:

1) Excellent fireproof property
2) Super peeling strength
3) Perfect cold resistance performance
4) Excellent surface flatness and smoothness
5) Superior weather, corrosion, pollutant resistance
6) Even coating, various colors
7) Superior impact resistance
8) Lightweight and easy to process
9) Easy to maintain

Application:

1) Gas piping, cables, building materials, etc (this product fills a gap in the domestic construction materials field, with performance indexes superior to panels manufactured overseas)
2) Curtain wall decoration for buildings where security is important, such as airports, hospitals and research centers
3) Curtain wallboards for outside walls of normal buildings
4) Renovations of old buildings and movable houses
5) Reformation and decoration for indoor walls, ceilings, bathrooms, kitchens and balconies
6) Facades
7) Billboards, exhibition desks and notice boards
8) Wallboards and ceilings for tunnels
9) Materials for industrial application, car and ship bodies

Exterior architecture cladding

Gas Station

Building Facade

Packaging & Shipping

Packaging Details

< 1 > Wooden box Or in bulk

< 2 > Weight: 5.5kg/M2 based on 0.5/4mm thickness

< 3 > Standard size: 1220x2440mm

< 4 > Qty/20'fcl: 4mm/2380M2 , 3mm/2977M2 with Wooden box

< 5 > Qty/40'fc: 4mm/4750M2 , 3mm/6200M2 in bulk

Delivery Detail

15 ~ 20days after got deposit.

Quality Control

The quality is core competence and development,we were established a complete Physics and Chemistry Lab with professional team.

According to the requirement of clients, the Lab is able to make precise tests and certification for various performance test standard of the products.

Such as the required glossiness, boiling water resistance, and resistance to change of temperature can be ensured by the physical performance test. The required coating thickness , pencil hardness, grinding resistance, soil resistance can be ensured by the coating performance test. The bending strength, and impact strength can be analyzed by the mechanical property test. The acid resistance , alkali resistance, oil resistance and salt-spry resistance can be analyzed by the solvent resistance performance test. Such tests ensure that the various performance targets of the Sunshine aluminum panels reach the requirements of industrial standards.

Color Chart

Why choose us

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer.

Q: How soon can I get a price quote?

A: With in 12 hours, once we got the your detail requirement.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the free sample but the freight charge should be collected..

Q: How long is your delivery time?

A: 15 - 20 days after got the deposit.

Q: Can I produced by my brand?

Yes,you can.

You just need to send your brand or LOGO design to us.

Q: What is the MOQ?

Due to high machine setup cost and shipping freight,our minimum order quantity is 1000 m^2.

Recommend you to order a 20''GP to save the packing and shipping cost.
