Specifications
paving block machine QTF3-20 machine to make concrete blocks export to south africa1.easy operation
2.100% pre-tested
concrete interlocking making machine QTF3-20 machine to make concrete blocks export to south africa
Main technical parameters of hollow /paving block machine /concrete interlocking making machine QTF3-20 machine to make concrete blocks export to south africa
Main vibration form | Platform vibration and pressure |
Cycle Time | 20 seconds |
Vibrating Frequency | 4600 rolls/minute |
Motors Power | 14.25KW |
Pallet Size | 680*530mm |
Raw Materials | Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes. |
Applied Products | concrete blocks, paving stones with or without face mix, garden and landscaping products, slabs, edgers, curbstones, grass blocks, slope blocks, interlocking blocks, etc. |
Applied Fields | widely used in buildings, road paving’s, squares, gardens, landscaping, city constructions, etc. |
Productivity of hollow /paving block machine /concrete interlocking making machine QTF3-20 machine to make concrete blocks export to south africa
Type | Sample | Size(mm) | Quantity | Molding cycle | QTY/Per hour |
Paver block mould | |
200*100*60 |
10pcs/mould |
15-20s |
1800pcs |
Paver block mould |
|
225*112.5*60 |
8pcs/mould |
15-20s |
1020pcs |
Paver block mould |
| 400*200*80 | 3pcs/mould | 15-20s | 540pcs |
Paver block mould |
| 200*160*60 | 6pcs/mould | 15-20s | 1080pcs |
Applied fields:
Widely used in buildings, road pavers, squares, gardens, landscaping, city constructions, etc.
Outstanding features: hollow /paving block machine /concrete interlocking making machine QTF3-20 machine to make concrete blocks export to south africa
other information:
with Reasonable design, compact structure,QTF3-20 concrete block making machine can realize thedirectional vibration . With frequency conversion brake can immediately cancel energy consumption and manual to board cloth can greatly reduce the labor intensity.
Pressurize to its upper and below, with strong rammer 3-20 concrete block making machine is especially suitable for high strength block production.
3-20 concrete block making machine can be used for Multi-purpose, with different mold 3-20 concrete block making machine can produce various specifications of the block
- FAST SHIPPING from our Linyi China Factory!
- Item shipped in 15-28 working days after payment is received depends on the quantity of the order.
- Item shipped by sea transpotation depending on size and weight of total order.
- Item only shipped to port listed on the invoice; Not responsible for shipping to wrong address.
- Bill of lading will be sent to you as soon as we ship the goods.
Guarantee
1.We can supply one year guarantee period for our brick making machines, if the client have the question ,they could call our service department number any time , we will supply per day 24 hours service .
2.Within one year, if the client meet the unsolvable questions ,we could fly to client place to help.
Linyihuali Co.Ltd. is located in Linyi City. Established in 2005,the specialty is engaged in the production, development and sales . After many years of research, senior engineer, our products has reached the international advanced level, good quality, low price, has attracted many foreign customers.
Clients all over the world
Contact Information |
By Phone:008613668691035 Email:sales03 at Tell:0086-539-8103579 Fax:0086-539-8103578 By Skype:hlmachine6 By Alibaba: We are always at your service! |
