Help CenterConcrete Mixer JS500 (HOT)
Related Products
Specifications
1.simple operate safely2. 3030*2520*2880mm
3.quality guarantee
4.ISO9001,CE
5. High efficiency and low energy
concrete mixer JS500 (HOT)
JS500 double axle concrete mixer can mix plasticity, lower plasticity, do rigid and various kinds of light quality concrete and sand oar. It is a kind of Multi-functional mixing machinery with high efficiency and low energy Consumption. With low noises mixing effect, it is suitable for high quality concrete mix of home working.
JS model double axes stirring machine is more advanced machine at present in our country, do well in mixing concrete, production is efficient, shorter time for mixing, low energy, noise is small. it can mix all kinds of concrete ,meeting many requirement. Alternative parts has long life, easily to repair and operate and so on, feed height which according to customer’s need is designed .it can be applied with concrete mixer transport machine and dumping car, working with concrete mixer make a concrete stirring machine ,it is very good production for all kinds of project land.
JS500 the Concrete mixer main technical parameters:
Charging volume: 800L
Discharging volume:500L
Production capacity:25m3/h
Electric motor power for mixing:18.5KW
Electric motor power for windlass:5.5KW
Water pump power:0.75KW
Maximum grain sizes of aggregate:scree 60mm
Weight of the whole machine:4500Kg
Overall dimension (L*W*H) :3030*2520*2880mm
SPECIFICATION OF JS500
Mosel |
JS500 |
||
Output capacity |
500L |
||
Input capacity |
800L |
||
Capacity |
≥25m3/h |
||
Max aggregate size |
80/60mm |
||
Agitating vane |
RPM |
35r/min |
|
Quantity |
2*7 |
||
Mixer motor |
Model |
Y180m-4 |
|
Power |
18.5kw |
||
Windless motor |
Model |
YEZ1325-4-B5 |
|
Power |
5.5kw |
||
Water pump motor |
Model |
50DWB20-8A |
|
Power |
7.5kw |
||
Hopping lifting speed |
18m/min |
||
Over size |
Transporting position |
3050*2300*2680mm |
|
|
Working position |
4461*3050*5225mm |
||
Weight |
4000kg |
||
Unloading height |
1500mm |
||
