JS500 cement mixer small

Specifications

JS500 cement mixer small
1.Discharging volume:500L.
2.Charging volume:800L.
3.Productivity:25cbm/h.

JS500 cement mixer small

JS500 is twin shaft compulsory concrete mixer, which can mix subarid rigid concrete, plasticility concrete, flolwability concrete, light aggregate concrete and various mortar. Drum sets with wear resistant cast liner and mixing blade, which is durable and easy to replace. Once JS500 concrete mixer is combined with various models batching machine, batching plant will come into being, which applies to various kinds of large & medium scale prefabricated factories and all kinds of construction sites, road, bridge, airports, tunnels and other projects.

This model concrete mixer is designed reasonable, compact structure, easy to operate and work stably, and it also has many advantages such as good mixing quality, high productivity, low energy consumption, low noise, and long life wearing parts.

Technical specifications of JS500 cement mixer small



Type		JS500
Discharge Capacity(L)		500L
Feed Capacity(L)		800L
Productivity(m3/h)		≥25m3/h
Maximum Aggregate Size		80/60mm
Mixing Blades	Rotation Speed	35r/min
	Number	2*7
Stirring Motor	Type	Y180m-4
	Power	18.5kw
Lifting Motor	Type	YEZ1325-4-B5
	Power	5.5kw
Pump Motor	Type	50DWB20-8A
	Power	7.5kw
The Average Rate of Hopper Movement		18m/min
Unload Material Height		1500mm
Overall Dimenssion	Transporting Status	3050*2300*2680mm
	Operating Status	4461*3050*5225mm
Machine Weight		4000kg
