Choclate Conching Machinery

Choclate Conching Machinery thumbnail-1
Choclate Conching Machinery thumbnail-2
Choclate Conching Machinery thumbnail-3
Choclate Conching Machinery thumbnail-4
Choclate Conching Machinery thumbnail-5
Choclate Conching Machinery thumbnail-6
Choclate Conching Machinery photo-1
Choclate Conching Machinery photo-2
Choclate Conching Machinery photo-3
Choclate Conching Machinery photo-4
Choclate Conching Machinery photo-5
Choclate Conching Machinery photo-6
US$ 150,000 - 300,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Huadong
Contact Supplier Request Quote Chat Now
Ningbo Huadong Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name Huadong
Model Number QHZ-I / II / III
Application Chocolate
Voltage 380V 50Hz
Power(W) 40kw
Weight 4500kg
Dimension(L*W*H) 85m*37m*28m
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Choclate conching machinery



This machine is used to produce multicolor decorating chocolate, stereo spherical & half stereo filled big chocolate, three-color decorating big chocolate, almond chocolate, biscuit chocolate, crispy mixing chocolate, multi-color chocolate with stick etc.

It uses servo driven depositor moulding system and has axis gang controlling depositor (can move horizontally & vertically), automatic opening & closing of stereo mould, automatic haptor demoulding, elevating type cooling tunnel etc.

Specification



  Production Capacity   1200~3000kg / 8hour
  Mold Size   450*225mm
  Casting Speed   10~12 disc / min
  Machine Power   40kw
  Compressed Air   0.8 cubic meters / min, 0.8Mpa
  The Total Number Of The Disk Mode   315
  Cooling Capacity   21800kcal/h
  Freezing Machine Power   15p
  Size Of Machine   8500*3700*2800cm
  Weight Of Machine   4500kg



                                                                                                     DiagramChoclate conching machinery







Video Show

Choclate conching machinery

Detail Show

 Choclate conching machineryChoclate conching machineryChoclate conching machineryChoclate conching machineryChoclate conching machineryChoclate conching machinery
