Help CenterTranmission Belt With CR or HNBR Synchronous/Timing Belt
Related Products
-
Timing Belt Industrial Belt,galvanlized Steel Cord Jointed Belt ,conveyor BeltUS$ 6 - 200MOQ: 10 Square Meters -
PU Industry Timing BeltUS$ 6 - 200MOQ: 10 Square Meters
-
Industrial Machine Timing BeltUS$ 6 - 200MOQ: 10 Square Meters
-
Rubber Double-sided Timing BeltUS$ 6 - 200MOQ: 10 Square Meters
-
Timing Belt Made In China ManufacturersUS$ 6 - 200MOQ: 10 Square Meters
Timing Belt
Timing Belt
Model: XL,L,H,XH,XXH,3M,5M,8M,14M,T5,T10,T20 Etc.
| Model | Tooth pitch(MM) | tooth height(MM) | total thickness(MM) |
| XL | 5.08 | 1.27 | 2.3 |
| L | 9.525 | 1.91 | 3.6 |
| H | 12.7 | 2.29 | 4.3 |
| XH | 22.225 | 6.35 | 11.2 |
| XXH | 31.75 | 9.53 | 15.7 |
| T5 | 5 | 1.2 | 2.2 |
| T10 | 10 | 2.5 | 4.5 |
| T20 | 20 | 5 | 8 |
| AT5 | 5 | 1.2 | 2.7 |
| AT10 | 10 | 2.5 | 5 |
| AT20 | 20 | 5 | 8 |
| 3M | 3 | 1.17 | 2.4 |
| 5M | 5 | 2.06 | 3.8 |
| 8M | 8 | 3.36 | 6 |
| 14M | 14 | 6.02 | 10 |
| 20M | 20 | 8.4 | 13.2 |
| S3M | 3 | 1.14 | 1.9 |
| S5M | 5 | 1.17 | 3.4 |
| S8M | 8 | 3.05 | 5.3 |
| S14M | 14 | 5.3 | 10.2 |
2. By Air or by Sea for batch goods, Airport/ Port receiving.
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: In general,25 days for batch goods.
Zhejiang farman industrial belt Co. Ltd., Specialized in the production and sale of various industrial belt transmission parts.our company to introduce advanced technology and equipment, production and sales in the mainland Chinese Farman brand industrial belt products, for our customers to provide more quality transmission and transportation products.
Welcome customers to provide opportunities for cooperation.
Farman product has: the plane conveyor beltcustomize a variety of patterns and colors of the running beltAntiskid beltskirt beltBaffle conveying beltWith V type guide strip conveyer beltnylon film base belt timing belt V-beltround beltTeflon conveyor beltcanvas belt A variety of special industrial belt processing etc..
1Q: Manufacturer or Trading company?
A: Imported polyamide, polyester, NBR and XNBR, etc. Most suppliers authorized for 5 years more.
A: Sure. Not only color, design, texture, but also labeling&marks and so on.
4Q: Samples?
A: Sure. Free sample. Normally 3 working days.
5Q: Quality Control?
A: Strict production flow and data to evaluate all steps; sheets track back each step.
