Help CenterHowo Transmission/ Volvo Transmission/Yutong Bus Manual Transmission Gearbox S580
Related Products
-
Qijing Transmission Gearbox Dump Truck Bearing 1280304027 for QJ805/5S-80/QJS5-80NegotiableMOQ: 1 Piece -
S5-80 QJ805 Iron Transmission Covering /covering 108301010NegotiableMOQ: 1 Piece
-
S5-80 QJ805 Transmission Covering 108301010NegotiableMOQ: 1 Piece
-
China Factory QJ805 S5-80 HOWO Truck Spare Parts 1096302076 Release Bearing AssemblyNegotiableMOQ: 1 Piece
-
QJ805 S5-80 Gearbox Release Bearing 1096302076NegotiableMOQ: 1 Piece
Specifications
1. Application: HOWO/Sinotruck, Volvo truck,Yutong bus2. 5S150GP,S690, 5S111GP,S1506,S580 provided
3.OEM service available
| Gearbox S5-80 / S5-120 Technical Data | |||||||
| Type | Rating Input Power (N.m) | Standard transmission ratio | |||||
| 1st | 2nd | 3rd | 4th | 5th | Reverse | ||
| Direct Speed | 800~1000 | 6.90 | 3.83 | 2.32 | 1.49 | 1.00 | 5.89 |
| Direct Speed | 6.90 | 4.13 | 2.32 | 1.49 | 1.00 | 5.89 | |
| Direct Speed | 6.11 | 3.39 | 2.05 | 1.32 | 1.00 | 5.22 | |
| Overdrive Speed | 6.11 | 3.15 | 1.71 | 1.00 | 0.78 | 5.22 | |
| Overdrive Speed | 6.35 | 3.27 | 1.77 | 1.00 | 0.81 | 5.42 | |
| Direct Speed | 5.82 | 3.23 | 1.96 | 1.26 | 1.00 | 4.97 | |
| Overdrive Speed | 5.82 | 3.23 | 1.79 | 1.00 | 0.74 | 4.97 | |
| Speedometer ratio | 1.545/2.0(Can be customized) | ||||||
| Total Weight | about 195kg | ||||||
| Oil Capacity | horizontal installation 12 L,vertical installation 10.5 L | ||||||
Products details:
Packing details:
1. wooden case 1pcs/case
2. Packaging according to your specification.
3. Private label package available
Our field:
1. 5 speed gearbox assembly & spare parts: S5-50, S5-60, S5-70, S5-80, S5-120
2. 6 speed gearbox assembly & spare parts: S6-80, S6-90, AK6-90, S6-100, S6-120, S6-150, S6-160
3. 9 speed gearbox assembly & spare parts: 5S-150GP, 5S-111GP
4. 16 speed gearbox auto parts: 16S109, 16S150, 16S151, 16S181, 16S220, 16S221, 16S251
5. Mercedes-Benz G60, G85 auto parts
View of our office:
Factory Equipment:
Clients:
Certificates:
Questions&Reply:
1. Do you have a need for products other than ZF?
If yes, we have parts for Mercedes, Eaton Fuller, MAN, DAF, etc.
2. Are your products used worldwide?
Yes, we supply US, South America, Asia, Middle East, Southeast Asia. Most ZF parts are universal in application.
3. Can you apply my logo or part number on the parts?
Yes, we can. Please provide sample or drawing.
4. Are you able to produce parts according to my sample or drawing?
Yes, we have engineers and technicians to make samples.
5. What type of packaging do you provide?
Standard packaging is plain, cardboard box and anti-rust wrapping. We can provide special packaging and logos per your specifications.
6. Who are we?
We are Chongqing Shield Gear & Transmission Co., Ltd., a worldwide distributor and manufacturer since 2005.
7. We can ship parts from any port in China.
