Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Latest Uv Printer Roll to Roll
Latest Uv Printer Roll to Roll
US$ 21,700 - 21,710
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, roll to roll
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Beijing Jiangsu Zhejiang Chengdu Shenzhen Xianggang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LED UV PrinterUS$ 15,700 - 15,800MOQ: 1 Set -
UV Inkjet Printer With DX7 Head, Digital Textile/Leather / PU / Wall Paper PrinterUS$ 16,000 - 16,100MOQ: 1 Set
-
Hot Sale Flex Banner Printing Machine, Digital UV Printing MachineUS$ 15,000 - 15,100MOQ: 1 Set
-
Latest 3.2m 1440dpi UV LED Printer With DX7 HeadsUS$ 21,100 - 21,110MOQ: 1 Set
-
Digital Large Format LED UV Inkjet Printer Price for SaleUS$ 25,570 - 25,580MOQ: 1 Set
Condition
New
Plate Type
Other, roll to roll
Place of Origin
Jiangsu, China
Brand Name
A-starjet
Model Number
7702L,7703L LED UV
Usage
Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade
Semi-Automatic
Voltage
AC220-240V,50-60Hz or AC110-120V, 50-60Hz
Gross Power
2500W, IR heater 1200W
Dimensions(L*W*H)
W x L x H: 4.30 x 0.90 x 1.25(M)
Weight
395kg
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
3.2M A-starjet LED UV Printer,7702L/7703L
Briefing:
Up to 1440Dpi provides finest details.
Suit for most media including leather,Fabric,semi-rigid substrates.
UV ink curing on surface instead of absorb by media,provide vividness,sharpness.
packing:
For 3.2M A-starjet LED UV Printer,7702L/7703L, Latest Uv Printer
Printer Dimension(M): W x L x H 4.30 x 0.90 x 1.25
Packing Dimension(M):W x L x H 4.50 x 0.98 x 0.70
Video on Youtube:
/watch?v=EqZji5GWJYc&list=PL3nfrqB1qbF
EuDZjiDmhgNyPFFk8bZz4n&index=5
Specifications
| Item | A-starjet 7702L UV | A-starjet 7703L UV | |||
| Print Head | Two DX7 print heads | Three DX7 print heads | |||
| Number of nozzles | 1440/Head | ||||
| Color | 4 Colors:KCMY/KCMY+White | ||||
| Resolution | 1440Dpi(Max) | ||||
| Height of head | 2-5mm | ||||
| Size of ink droplet | 1.5-21pl | ||||
| Printing width | 3000mm | 3000mm | |||
| Media width | 3300mm | 3300mm | |||
| Speed | 3 pass | 35.9m2/hour | 48m2/hour | ||
| 4 pass | 29m2/hour | 38m2/hour | |||
| 6 pass | 17m2/hour | 25m2/hour | |||
| 8 pass | 12.5m2/hour | 19m2/hour | |||
| Feeder/Take up | Yes | ||||
| Payload | 200kgs | 200kgs | |||
| Heating system | Print heater and Post heater with PID temperature control | ||||
| Ink | Environmental protection type LED UV ink | ||||
| Ink cartridge | Bulk ink supply | Bulk ink supply | |||
| RIP software | Iprint 3.8.2 Optional(Photoprint) | ||||
| Control software | Print console | ||||
| PC system | Win XP & Win 7 | ||||
| Power Voltage | AC220-24V 50-60Hz or AC110-120V 50-60Hz | ||||
| Environment | Temperature:20-50℃ ,Humidity:40-60% | ||||
| Printer Dimension | W4300× D900× H1250 | ||||
| Packing Dimension | W4500× D980× H700 | ||||
| Gross weight | 575Kgs | ||||
| Notice:A-starjet 7703 series printer all could use Color-White-Color mode for printing | |||||
samlas:
Optimal Vividness and Sharpness
Fabric Availbale
Emsed texture
Print directly on leather
