| 1. Backgroud of A-Starjet Flatbed UV LED Large Format Printer |
Officially A-Starjet only launched one A-Starjet 7702 Flatbed UV for DOT in Indonesia on Sep, 2013. Make a flatbed printer is extremely easy. For roll to roll large format printer, the Y-Axis is controlled by pinch rollers, media need to be fed. While flatbed printer, we only need to let the print main body moves. The media stay where it is.
The fact is that flatbed large format printer looks much large and the price is sky high. Metal is not expensive, Metal isn't expensive, the technology of control large format printer is same. That is the reason flatbed isn't our marjor products at all.
| 1. Advantages of A-Starjet Flatbed UV LED Large Format Printer |
Frankly speaking, flatbed large format printer isn't efficient because of the large body, need to locate exact position before print on end product etc.
However, the head's height is widely adjustable, most products are able to be put on flatbed and doesn't need to be moved when printing. All these factory make flatbed large format printer useful.
A-Starjet UV LED flatbed is actually modified by our partner in Guangzhou, it is a studio assist clients modified on printer. The leading time will be around 25 days.
| Item | A-Starjet 7702 UV LED Flatbed | A-Starjet 7703 UV LED Flatbed |
|||
| Print Head | Two DX7 Print Heads | Three DX7 Print Heads | |||
| Color | 4 Color:KCMY/KCMY+White Ink Optional | ||||
| Resolution | 1440Dpi(Max) | ||||
| Height of Head | 2-5mm | ||||
| Size of Ink Droplet | 1.5-21pl | ||||
| Printable Area |
1670×2600mm |
||||
| Media Width |
1800mm |
||||
| Speed | 3 pass | 30.7m²/hour | 44m²/hour | ||
| 4 pass | 23.6m²/hour | 33.7m²/hour | |||
| 6 pass | 15m²/hour | 24m²/hour | |||
| 8 pass | 11.5m²/hour | 16m²/hour | |||
| Platform | Armoured Glass |
||||
| Ink | LED UV | ||||
| Ink Cartridge | 8× 350ml ink cartridges | 12× 350ml ink cartridges | |||
| RIP Software | Iprint 3.8.2/Optional Photoprint, Wasatch, Onyx, SDK Available | ||||
| PC System | Win XP & Win 7 | ||||
| Power Voltage | AC220-24V 50-60Hz or AC110-120V 50-60Hz | ||||
| Environment | Temperature:20-50℃ ,Humidity:40-60% | ||||
| Printer Dimension | W2840× D3290× H850 (mm) | ||||
| Packing Dimension |
Printer Main Body: W2940× D980× H700 (mm) Flatbed: W3390× D1960× H1130 (mm) |
||||
| Net/Gross weight | TBD | ||||
| 4. UV LED Flatbed Digital Printer's Usage |
| 6. A-Starjet is Guaranteed to Be the Best Deal You Want to Get |
Reasonable Price
- Directly cooperate with R&D factory.
Comprehensive Guatantee Term
- Print heads are guaranteed when A-Starjet ink being used
- Motors are guaranteed for 6 months
- Printer's boards are guranteed for 15 months
- Counting from the day printer leaves factory
- Within guarantee time, send spare parts in advance and we'll cover all the freight
- After guarantee time, repair fee will be charged
Comfortable After-Sale Service
We are a highly efficient and experienced team.
- Online support Skype, Whats app, TeamView, Youtube, etc.
-
Official Service time from Monday to Saturday:
8:30am to 5:30pm(GMT +8), by experienced Engineers/Sale - 24 hours self-service available by Arthur's Youtube channel.
- All printer, parts in stock, able to ship out on any workday.
- Life-time free technical support from A-Starjet factory by engineers who have worked for A-Starjet for 6-7 years.
- Onsite Service is acceptable
