| Product Introduction |
A-Starjet 7702L Series Printer:
High Performance, High Quality Eco-Solvent Printers
A-Starjet 7702L Series inkjet printers go beyond extraordinary to deliver an awe-inspiring range of applications and versatility. Gamut-extending eco solvent inks enable you to accomplish anything from fine art reproduction,
wall décor and stunning backlits, to vehicle wraps and outdoor displays. Using the
A-Starjet 7702L Series inkjet printers’ superb quality, color fidelity, throughput and flexibility you’ll
go beyond the expected to capture more wallet share and deliver whatever your customers can imagine.
Go Beyond Conventional
1. Able to use encrypted DX7( first generation) decrease 15% cost per head. Compares to DX5, DX7 decrease 35% cost.
2.Head's voltage adjust separately, to compensate print head's performance.
3.Be professional, specialized platform to suits different material.
4.Practical speed and torque controllable take up system to handle different kinds of media.
5.Two versions feed system plus extra feeding system for lighter media.
| Product Details |
| Product Specification |
| Item | A-Starjet 7702L | A-Starjet 7703L | |||
| Print Head | Two DX7 print heads | Three DX7 print heads | |||
| Number of Nozzles | 1440/Head | ||||
| Color | 4 Colors:KCMY | ||||
| Resolution | 1440Dpi(Max) | ||||
| Height of Head | 2-5mm | ||||
| Size of Ink Droplet | 1.5-21pl | ||||
| Printing Width | 3200mm | 3200mm | |||
| Media Width | 3300mm | 3300mm | |||
| Speed | 3 pass | 40.5m2/hour | 55.5m2/hour | ||
| 4 pass | 32m2/hour | 43.5m2/hour | |||
| 6 pass | 19m2/hour | 29.3m2/hour | |||
| 8 pass | 13.8m2/hour | 22m2/hour | |||
| Feeder/Take up | Yes | ||||
| Payload | 200kgs | 200kgs | |||
| Heating System | Print heater and Post heater with PID temperature control,optional IR heater | ||||
| Ink | T5.5 eco-solvent ink | ||||
| ST5.5 water-base dye ink | |||||
| T7 reactive printing ink | |||||
| Ink Cartridge | Bulk ink supply | ||||
| RIP Software | Iprint 3.8.2 Optional(Photoprint&wastach) | ||||
| Control Software | Print console | ||||
| PC System | Win XP & Win 7 | ||||
| Power Voltage | AC220-24V 50-60Hz or AC110-120V 50-60Hz | ||||
| Environment | Temperature:20-50℃ ,Humidity:40-60% | ||||
| Printer Dimension | W4300× D900× H1250 | ||||
| Packing Dimension | W4500× D980× H700 | ||||
| Gross Weight | 560Kgs | ||||
Product Application
| Information Overview |
|
PRODUCT FEATURES: 1) Item Model: A-Starjet 7702L 2) Machine Body Materal: Aluminum Alloy 3) Printhead: Epson DX7 4) Resolution: 1440dpi (Max) 5) Size of Ink Droplet: 1.5-21Pl 6) RIP Software: Iprint 3.8.2 Optional(Photoprint&wastach)
Packaging Details: 1) Package Dimensions: W x L x H 4.5 x 0.98 x 0.70m 2) Quantity/Package: 1 Set 3) Gross Weight: 560Kg
Applications With eco solvent inks: Signage, Vehicle graphics, Point-of-purchase displays, Banners, Posters, Exhibition graphics, Window clings and more...
|
|
| Manufactory |
| Acheivements |
| Our Service |
1.Reasonable Price
- Directly cooperate with R&D factory.
2.Comprehensive Guatantee Term
- Print heads are guaranteed when A-Starjet ink being used
- Motors are guaranteed for 6 months
- Printer's boards are guranteed for 15 months
- Counting from the day printer leaves factory
- Within guarantee time, send spare parts in advance and we'll cover all the freight
- After guarantee time, repair fee will be charged
3.Comfortable After-Sale Service
We are a highly efficient and experienced team.
- Online support Skype, Whats app, TeamView, Youtube, etc.
-
Official Service time from Monday to Saturday:
8:30am to 5:30pm(GMT +8), by experienced Engineers/Sale - 24 hours self-service available by Arthur's Youtube channel.
- All printer, parts in stock, able to ship out on any workday.
- Life-time free technical support from A-Starjet factory by engineers who have worked for A-Starjet for 6-7 years.
- Onsite Service is acceptable
Great products with awesome quality!
You deserve it!
