A-Starjet 7703L Series Flex Banner Inkjet Printer, Eco-solvent, 10.5ft
Briefing: 3.2m print width with Epson DX7 print head.
The printer is equipment with
1) Take up system
2) Feeding system
3) Two inbuilt heaters
4) Cooling fan
* IR heater, Bulk Ink supply system are Optional
5) 110V/220V Eco-Solvent/Water-Base, Plug type
If use DX5 head, printer is able to install 1/2 heads.
If use DX7 head, it is able to install 1/2/3 heads.
Details A-Starjet Inkjet Printer 7703L Series
| Item | A-Starjet 7702L | A-Starjet 7703L | |||
| Print Head | Two DX7 print heads | Three DX7 print heads | |||
| Number of Nozzles | 1440/Head | ||||
| Color | 4 Colors:KCMY | ||||
| Resolution | 1440Dpi(Max) | ||||
| Height of Head | 2-5mm | ||||
| Size of Ink Droplet | 1.5-21pl | ||||
| Printing Width | 3200mm | 3200mm | |||
| Media Width | 3300mm | 3300mm | |||
| Speed | 3 pass | 40.5m2/hour | 55.5m2/hour | ||
| 4 pass | 32m2/hour | 43.5m2/hour | |||
| 6 pass | 19m2/hour | 29.3m2/hour | |||
| 8 pass | 13.8m2/hour | 22m2/hour | |||
| Feeder/Take up | Yes | ||||
| Payload | 200kgs | 200kgs | |||
| Heating System | Print heater and Post heater with PID temperature control,optional IR heater | ||||
| Ink | T5.5 eco-solvent ink | ||||
| ST5.5 water-base dye ink | |||||
| T7 reactive printing ink | |||||
| Ink Cartridge | Bulk ink supply | ||||
| RIP Software | Iprint 3.8.2 Optional(Photoprint&wastach) | ||||
| Control Software | Print console | ||||
| PC System | Win XP & Win 7 | ||||
| Power Voltage | AC220-24V 50-60Hz or AC110-120V 50-60Hz | ||||
| Environment | Temperature:20-50℃ ,Humidity:40-60% | ||||
| Printer Dimension | W4300× D900× H1250 | ||||
| Packing Dimension | W4500× D980× H700 | ||||
| Gross Weight | 560Kgs | ||||
Applications of A-Starjet Inkjet Printer 7703L Series:
1. PVC Type
Usage:Flex Banner, Knife Coated Substrate, Double Side Printing Banner PVC, Advertising Cloth, Adhesive Vinyl, One Way Vision, Mesh, Reflective, Banner, Reflective Vinyl.
2. Eco-solvent Inkjet Media
Fabric series: Flex Banner, Polyester Canvas, Pure Cotton Canvas and so on.
Wall Paper: Wall Paper with PVC on the surface, pure paper Wall Paper, wall paper with fabric on the surface, wall paper with fiber on the surface.
1. Able to use encrypted DX7( first generation) decrease 15% cost per head. Compares to DX5, DX7 decrease 35% cost.
2.Head's voltage adjust separately, to compensate print head's performance.
3.Be professional, specialized platform to suits different material.
4.Practical speed and torque controllable take up system to handle different kinds of media.
5.Two versions feed system plus extra feeding system for lighter media.
6.Media feeder system: through-core type or roller type.
7.The only step need for adjust the print heads is to insert the print head into the carriage. It doesn’t need to be adjusted for several times and dairy maintenance is quite easy and can be learned quickly.
8.Eco-solvent ink: it is eco-friendly, the smell of the ink is light which is suitable to use the printing media in indoor and outdoor both.
- All parts directly contact with ink are not guaranteed except use A-Starjet's ink
- 5 months guaranteed for DC motor
- 15 months for all Boards
- Counting from the day that printer leaves factory
- Within Guarantee time, factory covers freight for sending parts
- Working time: Monday to Saturday--8:30 a.m. to 11:30a.m. , 12:30 p.m. to 17:30 p.m. Personally, every day's 20:00 p.m. to 22:30 p.m. is also my working time.
Speed, stability, precision, all those factors do matter for highly competitive signage market, we get them and offer you the A-starjet inkjet printer 7703 series. The printer reaches 45sqm per hour at production mode with three DX7. Save cost of adding extra printer.
In May 2009, we successfully launched the A-starjet series printers, the high-precision indoor&outdoor printers, making great influence in the market. The machine is mainly used in the fields of indoor&outdoor advertising, labels and signs, textile printing, decoration, gifts, wedding photos, and so on. Based on customer particular requests, we can provide the overall resolution packages refer to machine/software design, printing technique, ink development etc.
Our office and factory
