Help CenterNylon Plastic Dowel for Screw Spike, Railway Accessories Made in Turkey
Related Products
-
Nylon Plastic Dowel for Railroad, Railway AccessoriesUS$ 0.5 - 0.8MOQ: 10000 Units -
Nylon Rail Plastic Dowel, Railway Accessories, Made in TurkeyUS$ 0.2 - 0.5MOQ: 10000 Units
-
Rail Plastic SleeveUS$ 0.5 - 0.8MOQ: 10000 Units
-
Railway Dowel, Railroad Insert, Rail SleeveUS$ 0.5 - 0.8MOQ: 10000 Units
-
Rail InsulatorUS$ 0.5 - 0.8MOQ: 10000 Units
Specifications
Rail Sleeve1, Made in Turkey
2, Punctual Delivery
3, Feedback within 6 hours
4, Nice Support
- 14 pcs Engel Injection Machine (All 2013 Model).
-1 pc Kraus Maffei-800 Tons
- Our Injection Machines are from 80 Tons to 8000 Tons (150 Gr. - 4000 Gr.)
In the awareness that our services that much large and continuous would only be possible by team-work, and with our staff possessing knowledge and skill based on modern technology, within the frame of DIN, ISO 9001 and TSEK Standards and Norms, we continue our services in our plants having 6000 m² covered, 5000 m² open area, for 24 hours a day. We possess dynamic and technical departments with broadly equipped in order to reply rapid developments in industry and construction sectors. We can manufacture all types of plastic extrusin and injection products in conformity with requested technical requirements, specifications and characteristics.
Rail plastic sleeve is pressed in concrete sleeper and assembled with sleeper screws, guide plates and rail clip to fix the rail.
Our rail plastic sleeve is made using either HDPE or PA6 and the product color is available in white, black and dark brown.
HDPE Rail Sleeve
| No. | Technical Parameter | Unit | Technical Requirement | Value |
| 1 | Density | g/cm3 | 0.95-0.98 | 0.95 |
| 2 | Tensile Strength | Mpa | ≥19 | 19 |
| 3 | Elongation | % | >80 | 150 |
| 4 | Melting Point | ℃ | 170-190 | 190 |
| 5 | Insulation Resistance | Ω | ≥1×1010 | 3.5 ×1010 |
| 6 | Hardness | A | ≥98 | 98(A) |
PA6 Rail Plastic Sleeve
PA6: Nylon 66.69%, Glass Fiber 30%, Other 1%
| No. | Technical Parameter | Unit | Technical Requirement | Value |
| 1 | Density | g/ cm | 1.3-1.45 | 1.45 |
| 2 | Tensile Strength | Mpa | ≥170 | 178 |
| 3 | Elongation | % | ≤4.4 | 4.0 |
| 4 | Bending Strength | Mpa | ≥250 | 290 |
| 5 | Impact Strength (No gap) | KJ/m2 | ≥80 | 85 |
| 6 | Melting Point | ℃ | 250℃ -270 | 270 |
| 7 | Insulation Resistance | Ω | ≥1×108 | 5×108 |
| 8 | Glass Fiber Content | % | 30-35 | 35 |
| 9 | Hardness | HRR | ≥110 | 118 |
Adhering to our quality first policy, GURBETCILER pays great attention to quality control management. We have been granted ISO9001-2008 certificates. We have a full plastic set of inspection instruments to ensure all our rail plastic sleeve are of high quality and up to customers' requirements.
