Popular 10x38 Midget Solar pv Fuse

Name: Popular 10x38 Midget Solar pv Fuse
Brand: REOMAX
SKU: 131983363
Availability: InStock

Dongguan Tianrui Electronic Co., Ltd.

Popular 10x38 Midget Solar pv Fuse thumbnail-1

Popular 10x38 Midget Solar pv Fuse photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

REOMAX

Model Number:

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen HK

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name REOMAX

Model Number PV

Usage Other, High Voltage, Solar pv current overlaod protection

Breaking Capacity Other, High, High

Safety Standards Other, UL CE, UL CE

Product Description

Main products include glass / ceramic cartridge fuses, thermal cutoffs, thermostats, automotive fuses, miniature fuses, SMD fuses, resettable fuses, fuse blocks, holders & clips.

Our tube fuse dimension covers: 3.6x10mm 4x11mm 5x15mm/2AG 6x30mm/3AG 6.3x32mm 6x25mm 10x38mm in both glass tube and ceramic

Ratings of the 10x38 1000V midget solar pv fuse

Cylindrical Ferrule	Current Rating	Voltage Rating	Energy Integrals I²t (A²s)		Watts Loss(W)		Breaking Capacity
Cylindrical Ferrule	Current Rating	Voltage Rating	Pre-Arcing	Total@1000V	0.8In	In	UL 10kA IEC 33kA Time Constant 1 - 3ms
PV - 1A 10F	1A	1000Vdc	0.15	0.4	0.8	1.5
PV - 2A 10F	2A	1000Vdc	1.2	3.4	0.6	1.0
PV - 3A 10F	3A	1000Vdc	4	11	0.8	1.3
PV - 3.5A 10F	3.5A	1000Vdc	6.6	18	0.9	1.4
PV - 4A 10F	4A	1000Vdc	9.5	26	1.0	1.5
PV - 5A 10F	5A	1000Vdc	19	50	1.0	1.6
PV - 6A 10F	6A	1000Vdc	30	90	1.1	1.8
PV - 8A 10F	8A	1000Vdc	3	32	1.2	2.1
PV - 10A 10F	10A	1000Vdc	7	70	1.2	2.3
PV - 12A 10F	12A	1000Vdc	12	120	1.5	2.7
PV - 15A 10F	15A	1000Vdc	22	220	1.7	2.9
PV - 20A 10F	20A	1000Vdc	34	350	2.1	3.6
PV - 25A 10F	25A	1000Vdc	325	1860**	1.65	2.91
PV - 30A 10F	30A	1000Vdc	536	3360**	1.65	3.31
**Total I²t @20KA IR. Rating 35A&40A are customized.
