SOLAR PV 10x38 1000V 20A Fuse

SOLAR PV 10x38 1000V 20A Fuse photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
REOMAX
Model Number:
PV
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen HK
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name REOMAX
Model Number PV
Usage Other, High Voltage, Photovoltaic Systems protection up to 1000vdc
Breaking Capacity Other, High, High
Safety Standards Other, UL CE, UL CE
Product Description

Main products include glass / ceramic cartridge fuses, thermal cutoffs, thermostats, automotive fuses, miniature fuses, SMD fuses, resettable fuses, fuse blocks, holders & clips.



Ratings of the 10x38 1000V pv fuse

Cylindrical

Ferrule

Current

Rating

Voltage Rating

Energy Integrals I²t (A²s)

Watts Loss(W)

Breaking Capacity

Pre-Arcing

Total@1000V

0.8In

In

UL 10kA

IEC 33kA

Time Constant

1 - 3ms



PV - 1A 10F

1A

1000Vdc

0.15

0.4

0.8

1.5

PV - 2A 10F

2A

1000Vdc

1.2

3.4

0.6

1.0

PV - 3A 10F

3A

1000Vdc

4

11

0.8

1.3

PV - 3.5A 10F

3.5A

1000Vdc

6.6

18

0.9

1.4

PV - 4A 10F

4A

1000Vdc

9.5

26

1.0

1.5

PV - 5A 10F

5A

1000Vdc

19

50

1.0

1.6

PV - 6A 10F

6A

1000Vdc

30

90

1.1

1.8

PV - 8A 10F

8A

1000Vdc

3

32

1.2

2.1

PV - 10A 10F

10A

1000Vdc

7

70

1.2

2.3

PV - 12A 10F

12A

1000Vdc

12

120

1.5

2.7

PV - 15A 10F

15A

1000Vdc

22

220

1.7

2.9

PV - 20A 10F

20A

1000Vdc

34

350

2.1

3.6

PV - 25A 10F

25A

1000Vdc

325

1860**

1.65

2.91

PV - 30A 10F

30A

1000Vdc

536

3360**

1.65

3.31

**Total I²t @20KA IR.

Rating 35A&40A are customized.



 Picture of the 10x38 1000V pv fuse

SOLAR PV 10x38 1000V 20A fuse

Company Information

 Recommended 10x38 1000V PV fuse holders

SOLAR PV 10x38 1000V 20A fuse

Related 10x38 fuses (volts available: 500V 600V 660V)

SOLAR PV 10x38 1000V 20A fuseSOLAR PV 10x38 1000V 20A fuseSOLAR PV 10x38 1000V 20A fuse



PLEASE CONTACT ME FOR MORE ABOUT 10X38 FUSES

Packaging & Shipping
  • Sample shipment: International express to be collected
  • Goods shipment: International express, airport to airport, sea
