BNF series Hydraulic Torque Generator

BNF series Hydraulic Torque Generator

• 4.9 cubic inch displacement

• 608 in. lbs. of torque output

• 1000 psi maximum working pressure

• 7/8" OD shafts at each end with woodruff key slot and 5/16" pinhole

• 4.0 gpm recommended flow requirement

• Needle bearings on output shaft for side load capability and longer life
• 4.56" between mounting faces

• 9.18" overall length including shafts

• 3.62" maximum diameter

  NOTE
  PORT Block is needed and adds .95 inch to height of 227-1017


The 227-1017 Has manifold ports - and requires a port block adapter, which is included in this price.
