BMM-70 Series Hydraulic Motor
US$ 60 - 90
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Type:
Hydraulic Motors
Model Number:
BMM
Brand Name:
tpf
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BMP1 Hydraulic Motor PriceUS$ 60 - 80MOQ: 20 Pieces -
BYM Gerotor Hydraulic MotorsUS$ 60 - 80MOQ: 20 Pieces
-
BM3 Hydraulic Motor TotaryNegotiableMOQ: 20 Pieces
-
BMM Rear Ports Hydraulic Motor MiniUS$ 60 - 80MOQ: 20 Pieces
-
BMM Side Ports Small Volumn Which Replace EATON 129 SERIES OBITAL HYDRALUIC MOTORUS$ 60 - 90MOQ: 20 Pieces
Type
Hydraulic Motors
Model Number
BMM
Brand Name
tpf
Place of Origin
Jiangsu, China
BMM series hydraulic motor
BMM series motor are small volume, economical type, which is designed with shaft distribution flow, which adapt the Gerotor gear set design and provide compact volume, high power and low weigth
| Type | BMM | |
| 70 | ||
| Displacement (cm3/rev.) | 70.5 | |
| Max. speed (rpm) | cont. | 285 |
| int. | 355 | |
| cont. | 64 | |
| Max. torque (N•m) | int. | 88 |
| peak | 100 | |
| Max. output (k W) | cont. | 1.6 |
| int. | 3.2 | |
| Max. pressure drop (MPa) | cont. | 7 |
| int. | 10 | |
| peak | 13 | |
| Max. flow (L/min) | cont. | 20 |
| int. | 25 | |
| Weight (kg) | 2.8 | |
| Option: | Application: | |
| - Model - Spool valve, gerotor; | *Conveyors | |
| - With or without flange; | *Textile machines | |
| - Side and rear ports; | *Machine tools | |
| - Shaft - straight and splined; | *Mining machinery | |
| - Flange-circle or Rhomb flange | *Construction plant equipment | |
| - Three ports - Metric /UNC and BSPP; | *Access platforms | |
| - Color-Blue, grey ,black ,yellow |
We can produce hydraulic motor which replace Danfoss OMM .
| OMM | ||||||
| Displacement (cc) | ||||||
| Code | 8 | 12.5 | 20 | 32 | 40 | 50 |
| 151G | 151G-0040 | 151G-0001 | 151G-0002 | 151G-0003 | 151G-0277 | 151G-0037 |
| 152G | 151G-0041 | 151G-0004 | 151G-0005 | 151G-0006 | 151G-0279 | 151G-0013 |
| 153G | 151G-0048 | 151G-0031 | 151G-0032 | 151G-0033 | - | 151G-5032 |
| 154G | 151G-0049 | 151G-0034 | 151G-0035 | 151G-0036 | - | 151G-0094 |
| 155G | 151G-0046 | 151G-0024 | 151G-0025 | 151G-0026 | - | - |
| 156G | 151G-0047 | 151G-0027 | 151G-0028 | 151G-0029 | 151G-0294 | - |
All of above code ,our BMM series motor can replace them .Welcom to enquiry .
