BMSJ Series Orbital Motor
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Hydraulic Motors
Model Number:
BMSJ
Brand Name:
TPF
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BMSY Series Hydraulic Motor RotaryUS$ 95 - 145MOQ: 10 Pieces -
FPRD Series Overcenter Valve for Bmr MotorUS$ 54 - 55MOQ: 10 Pieces
-
FYRHD Series Crossover Relief Valves for BMR/BMP MotorUS$ 30 - 60MOQ: 10 Pieces
-
WGB Series Hydraulic Motor Planetary GearboxNegotiableMOQ: 2 Pieces
-
BMT Series Low Speed High Torque Hydraulic MotorNegotiableMOQ: 5 Pieces
Type
Hydraulic Motors
Model Number
BMSJ
Brand Name
TPF
Place of Origin
Jiangsu, China
BMSJ series hydralic orbital motor:
One type of bearingless motor,Which can charlynn 106 series .The bearingless motor is especially suited for applications such as gear boxes, winchdrives, reel and roll drives.
| Type | BMSJ | BMSJ | BMSJ | BMSJ | BMSJ | BMSJ | BMSJ | BMSJ | ||
| 80 | 100 | 125 | 160 | 40 | 250 | 315 | 375 | |||
| Geometric displacement | (cc/rev.) | 80.6 | 100.8 | 125 | 160 | 200 | 250 | 314.5 | 370 | |
| Max.speed | (rpm) | rated | 675 | 540 | 432 | 337 | 270 | 216 | 171 | 145 |
| cont. | 800 | 748 | 600 | 470 | 375 | 300 | 240 | 200 | ||
| int. | 988 | 900 | 720 | 560 | 450 | 360 | 280 | 240 | ||
| Max.torque | (N*m) | rated | 175 | 220 | 273 | 316 | 340 | 450 | 560 | 536 |
| cont. | 190 | 240 | 310 | 316 | 400 | 450 | 560 | 536 | ||
| int. | 240 | 300 | 370 | 430 | 466 | 540 | 658 | 645 | ||
| peak | 260 | 320 | 400 | 472 | 650 | 690 | 740 | 751 | ||
| Max.output | (kW) | rated | 12.4 | 12.4 | 12.4 | 11.2 | 9.6 | 10.2 | 10 | 8.6 |
| cont. | 15.9 | 18.8 | 19.5 | 15.6 | 15.7 | 14.1 | 14.1 | 11.8 | ||
| int. | 20.1 | 23.5 | 23.2 | 21.2 | 18.3 | 17.0 | 18.9 | 17 | ||
| ure drop | (MPa) | rated | 16 | 16 | 16 | 15 | 12.5 | 12.5 | 12 | 10 |
| cont. | 17.5 | 17.5 | 17.5 | 15 | 14 | 12.5 | 12 | 10 | ||
| int. | 21 | 21 | 21 | 21 | 16 | 16 | 14 | 12 | ||
| peak | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 20 | 18.5 | 14 | ||
| Max.flow | (L/min) | cont. | 65 | 75 | 75 | 75 | 75 | 75 | 75 | 75 |
| int. | 80 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | ||
| Weight | (kg) | 9.8 | 10 | 10.3 | 10.7 | 11.1 | 11.6 | 12.3 | 12.6 | |
BMSJ
