320240 Dot-matrix Lcd Module With Controller RA8835 GH320240-5703

320240 Dot-matrix Lcd Module With Controller RA8835 GH320240-5703 photo-1
US$ 1 - 20 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Huayuan
Model Number:
GH320240-5703
Payment & Shipping
Payment Methods:
Port of Shipment:
Baoan airport of Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hunan, China
Brand Name Huayuan
Model Number GH320240-5703
Type Graphic

320x240 5.7 inch LCD monitor ,FSTN STN 5.7 inch LCD module with IC RA8875 PCB controller board

320240 Dot-matrix lcd module with controller RA8835 GH320240-5703



Specification



Specification



Model: GH320240-5703
Construction TAB
Display Type STN,Negative,Transmissive
Operating Voltage (VDD) 3.3V,5V
Backlight Voltage(VBL) 3.3V,5V
Operating Temperature (degree Celsius) -20~70
Storage Temperature (degree Celsius) -30~80
Viewing Direction 12:00
Dot Matrix 320*240
Viewing Area 122.00*92.00
Active Area 115.17*86.37
Outline Dimension 159.70*109.00*10.60
Controller RA8835
Backlight LED,White
Drawing



Drawing



Related product



Related Products



Character lcd module: 8x1, 8x2, 16x1, 16x2, 16x4, 20x2, 20x4, etc.

Graphic lcd module: 122x32, 128x64, 128x32,192x64, 24064, 240x128, 320x240, etc.

TFT lcd display: 1.44", 1.77", 2", 2.2", 2.4", 2.8", 3", 3.2", 3.5", 4", 4.3", 5",5.5", 5.7", 6.2", 7", 8", 9", 9.7", 10.1", 17",etc.

TN/STN/FSTN/HTN/VA segment customized lcd LED backlight panel

All kinds of LCD Module can customized.

 320240 Dot-matrix lcd module with controller RA8835 GH320240-5703

320240 Dot-matrix lcd module with controller RA8835 GH320240-5703





Production Process



Production Process

320240 Dot-matrix lcd module with controller RA8835 GH320240-5703
